Product Name:Digital Output
Brand Name:Honeywell
Model Number:900H03-0102
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Honeywell |
Model Number: |
900H03-0102 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Description |
|---|---|
| Product Model | 900H03-0102 |
| Output Channels | 8-point AC digital outputs |
| Output Type | Triac (zero-cross switching) |
| Operating Voltage | 85–240 VAC |
| Frequency Range | 47–63 Hz |
| Maximum Load Current | 2A per channel, 8A total |
| Peak Voltage | 250 VAC |
| Response Time | ≤ 3 ms + 0.5 cycle |
| Isolation | Output-to-output & logic isolation |
| Protection | MOV surge protection |
| Fuse Type | 3.15A time-lag per channel |
| Dimensions | 137 mm × 35.6 mm × 35.6 mm |
| Weight | ~230 g |
The 900H03-0102 is a high-performance 8-channel AC digital output solution designed for industrial automation systems requiring reliable load switching and stable signal control. Built on the ControlEdge 900 platform, it delivers isolated solid-state Triac outputs optimized for fast and precise ON/OFF operations in demanding process environments.
The 900H03-0102 features zero-cross switching technology to reduce electrical stress and enhance system longevity. Each channel provides individual galvanic isolation, integrated MOV protection, and a replaceable fuse, ensuring robust protection against surges and overload conditions. LED indicators offer real-time channel and module status monitoring.
Designed for seamless integration, the 900H03-0102 supports flexible installation with Euro-style terminal blocks and compatibility with ControlEdge HC900 systems, making it ideal for scalable industrial control architectures.
Q1: What type of outputs does the 900H03-0102 support?
A1: It provides 8-channel AC Triac solid-state outputs with zero-cross switching.
Q2: Is each output channel isolated?
A2: Yes, each channel has individual galvanic isolation for safe operation.
Q3: What protection features are included?
A3: It includes MOV surge protection and a replaceable fuse per output channel.
Q4: What is the operating voltage range?
A4: The module supports 85 VAC to 240 VAC industrial power systems.
Q5: Can it be used in harsh environments?
A5: Yes, it is designed for industrial applications with high noise and vibration resistance.
| Model | Description |
|---|---|
| 900B01-0101 | Analog Output Module, 4-channel isolated 0–21.8 mA output, high-precision industrial control module |
| 900B08-0202 | 8-channel analog output module for scalable process control applications |
| 900B01-0301 | 4-channel analog output module with enhanced current loop performance |
| 900A16-0103 | High-level analog input module for process signal acquisition |
| 900G03-0202 | Digital input module for AC voltage signal monitoring |
| 900H03-0202 | Digital output module for AC load switching control |
| 900P01-0301 | 60W AC power supply module for ControlEdge system support |
