Honeywell FC-PDB-0824P reliable 24VDC power distribution board Ready For Ship

Honeywell FC-PDB-0824P reliable 24VDC power distribution board Ready For Ship

Product Name:reliable 24VDC power distribution board

Brand Name:Honeywell

Model Number:FC-PDB-0824P

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell fc pdb 0824p reliable 24vdc power distribution board ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	FC-PDB-0824P
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Model	FC-PDB-0824P V1.0
Manufacturer	Honeywell
Product Type	24VDC Power Distribution Board
Power Distribution	24VDC Field Power Supply Distribution
Compatible Cables	FS-PDC-MB24-1P / 2P / 3P
Input Connector	Weidmuller BVZ 7.62HP/02F SN
Field Connector	Weidmuller BLZ 5.08/2F SN SW
Fuse Type	Slow Acting Fuse
Maximum Fuse Rating	2 AT
Fuse Dimension	5 × 20 mm
Mounting Method	DIN Rail TS32 / TS35 × 7.5
Used Rail Length	95 mm
Approvals	CE (UL, TUV, CSA Pending)
Operating Voltage	24VDC
Module Dimension	94 × 109 × 71 mm
Weight	Approx. 0.5 kg*
Application	Safety Manager Power Distribution Systems

Description

FC-PDB-0824P is a reliable 24VDC power distribution board engineered for Honeywell Safety Manager systems, providing efficient power routing and protection for field termination assemblies and distributed control equipment. Designed for seamless integration with FS-PDC-MB24-1P, FS-PDC-MB24-2P, and FS-PDC-MB24-3P power distribution cables, it ensures stable power delivery across critical industrial automation networks.

Featuring keyed Weidmuller connectors and fused output protection, FC-PDB-0824P enhances system safety while simplifying installation and maintenance. Its DIN-rail mounting design allows easy deployment in control cabinets, making it suitable for both new installations and system upgrades.

Widely used in process industries, power generation facilities, and safety instrumented systems, FC-PDB-0824P helps maintain uninterrupted 24VDC distribution, improves operational reliability, and supports the demanding requirements of mission-critical automation applications.
