Honeywell FS-MB-0002 high-capacity DC power distribution solution Ready For Ship

Honeywell FS-MB-0002 high-capacity DC power distribution solution Ready For Ship

Product Name:high-capacity DC power distribution solution

Brand Name:Honeywell

Model Number:FS-MB-0002

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell fs mb 0002 high capacity dc power distribution solution ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	FS-MB-0002
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product	FS-MB-0002 Mains Power Rail for Safety Manager SC power distribution systems
Function	DC power distribution from redundant power supplies to I/O and control modules
Voltage Range	24Vdc to 110Vdc industrial DC power input support
Current Capacity	Up to 200A total rail load capability for high-density systems
Structure	4-section copper rail assembly with end caps and modular design
Connector Types	Supports JCK (Jackscrew) and STR (Squeeze-To-Release) connectors
Connection Points	48 total terminal positions for flexible wiring distribution
Dimension	649 x 5.08 x 34.8 mm compact rail design for cabinet integration
Weight	Approx. 1.5 kg lightweight industrial mounting structure

Description

The FS-MB-0002 mains power rail is a high-capacity DC power distribution solution designed for Safety Manager SC systems, supporting a voltage range of 24Vdc to 110Vdc. It efficiently delivers power from redundant supplies to multiple field modules, ensuring stable and reliable energy distribution in safety-critical industrial environments. FS-MB-0002

Built with a four-section copper rail structure, the FS-MB-0002 provides up to 48 connection points and a maximum current capacity of 200A. It supports both JCK and STR connector types, enabling flexible installation and secure electrical interfacing across control cabinet architectures.

Engineered for industrial robustness, the FS-MB-0002 ensures efficient power routing for distributed safety I/O systems, minimizing wiring complexity while improving system reliability and maintenance efficiency in large-scale automation projects.

Applications

Power plants: Used for generator set monitoring systems, relay protection circuits, and stable auxiliary power distribution.
Substations: Enables high-reliability bus protection, switchyard control, and electrical signal power supply networks.
Chemical plants: Supports process automation systems with safe and stable DC power routing in hazardous environments.
Steel mills: Provides durable power distribution under high temperature, vibration, and electromagnetic interference conditions.
Machinery manufacturing: Applied in automated production lines, robotic systems, and industrial control cabinet power architecture.

Features

High-capacity 200A DC power distribution capability
Modular 4-section copper rail structure for scalable installation
Dual connector compatibility: JCK and STR types supported
Designed for redundant power supply integration
Compact layout optimized for industrial control cabinets

Functions

Distributes DC power from redundant sources to multiple safety modules
Supports flexible connection via 48 terminal positions
Provides stable current routing for distributed automation systems
Reduces wiring complexity in large control panels
Ensures continuous power availability for safety-critical operations

FAQ

Q1: What is FS-MB-0002 used for?
A1: It is used for distributing DC power in Safety Manager SC systems across multiple control modules.

Q2: What is the maximum current capacity of FS-MB-0002?
A2: The rail supports up to 200A total current distribution.

Q3: Which connector types are supported?
A3: It supports JCK (Jackscrew) and STR (Squeeze-To-Release) connectors.

Q4: How many connection points does FS-MB-0002 provide?
A4: It provides 48 connection points across its four-section design.

Q5: Where is FS-MB-0002 typically applied?
A5: It is widely used in power plants, substations, chemical plants, steel mills, and industrial automation systems.
