Honeywell MC-TAIH04 51305900-175 HLAI HART Field Termination Assembly Ready For Ship

Honeywell MC-TAIH04 51305900-175 HLAI HART Field Termination Assembly Ready For Ship

Product Name:HLAI HART Field Termination Assembly

Brand Name:Honeywell

Model Number:MC-TAIH04 51305900-175

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

honeywell mc taih04 51305900 175 hlai hart field termination assembly ready for ship-1

Overview
Contact us
Specifications
Description
Applications
Control & Communication
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Honeywell
Model Number:	MC-TAIH04 51305900-175
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact us

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	MC-TAIH04 51305900-175, Honeywell HLAI HART Field Termination Assembly for Experion PKS automation systems.
Product Type:	High-Level Analog Input (HLAI) HART Field Termination Assembly (FTA).
System Compatibility:	Designed for Honeywell Experion PKS, C200, and compatible Process Manager I/O systems.
Signal Type:	Supports high-level analog input signals with integrated HART communication capability.
Number of Channels:	16 analog input channels for field instrument connectivity.
Terminal Type:	C-Type field termination configuration for organized industrial wiring.
Mounting Size:	Size A mounting arrangement for compatible Honeywell cabinets and I/O assemblies.
Communication Support:	Compatible with HART-enabled transmitters for digital diagnostics and configuration.
Dimensions:	Compact industrial FTA design, suitable for standard Honeywell control cabinets.
Weight:	Approximately 0.4 kg (typical installed module weight).
Application:	Industrial process measurement, analog signal termination, and HART field device integration.

Description

The MC-TAIH04 51305900-175 is a high-level analog input Field Termination Assembly (FTA) developed for Honeywell Experion PKS and C200 Process Manager control systems. Designed to support 16 HART-enabled analog input channels, this FTA provides secure field wiring termination and dependable signal transmission between process instruments and I/O modules. Its optimized terminal layout simplifies installation while improving long-term wiring reliability in industrial automation environments.

Built for demanding process control applications, the MC-TAIH04 supports accurate acquisition of HART-compatible analog signals from transmitters measuring pressure, temperature, flow, and level. The module helps reduce installation complexity, enhances maintenance efficiency, and improves overall system availability by providing organized field connections and reliable communication.

Compatible with Honeywell Experion PKS, C200, and related MC-TAIH03, MC-TAIH14, and MC-TAIH15 analog input solutions, the MC-TAIH04 51305900-175 is widely deployed in power generation, oil & gas, chemical processing, pharmaceutical manufacturing, and other continuous process industries requiring dependable HART signal integration.

Applications

Power plants: Connects HART transmitters for turbine monitoring, boiler instrumentation, and process measurement systems.
Substations: Acquires analog process signals from auxiliary equipment, environmental monitoring, and electrical balance-of-plant systems.
Chemical plants: Integrates pressure, temperature, flow, and level transmitters into Experion process control networks.
Steel mills: Collects analog process measurements from furnaces, cooling systems, and production equipment operating in harsh environments.
Oil & gas facilities: Interfaces HART field instruments for refinery automation, pipeline monitoring, and process safety systems.
Water treatment plants: Supports analog instrumentation for flow control, chemical dosing, filtration, and pump monitoring.
Pharmaceutical manufacturing: Provides reliable HART signal termination for validated process control and batch production systems.

Control & Communication

Supports 16 HART-enabled analog input channels for industrial instrumentation.
Enables reliable communication between field transmitters and Honeywell control systems.
Compatible with Experion PKS and C200 distributed control architectures.
Supports HART diagnostics, configuration, and digital device communication.
Provides organized field wiring for simplified installation and maintenance.
Optimized for stable analog signal transmission with minimal interference.
Enhances communication reliability in continuous process automation.
Suitable for mission-critical industrial measurement applications.

Features and Benefits

Supports 16-channel high-level analog input applications.
HART compatibility enables advanced transmitter diagnostics and remote configuration.
Compact field termination design simplifies cabinet layout and wiring management.
Improves installation efficiency while reducing maintenance time.
Reliable terminal construction enhances long-term signal integrity.
Fully compatible with Honeywell Experion PKS control platforms.
Designed for continuous industrial operation in demanding process environments.
Ideal for modernization, expansion, and maintenance of Honeywell DCS installations.

FAQ

Q1: What is the primary function of the MC-TAIH04 51305900-175?
A1: The MC-TAIH04 51305900-175 is a Honeywell Field Termination Assembly that connects 16 HART-enabled analog input channels to Experion PKS and C200 control systems.

Q2: How many analog input channels does the MC-TAIH04 support?
A2: The module supports 16 high-level analog input channels for industrial process instrumentation.

Q3: Does the MC-TAIH04 support HART communication?
A3: Yes. It is specifically designed for HART-compatible analog transmitters, enabling digital diagnostics and device configuration.

Q4: Which Honeywell systems are compatible with the MC-TAIH04?
A4: The module is compatible with Honeywell Experion PKS, C200 Process Manager, and related Honeywell I/O architectures.

Q5: Which industries commonly use the MC-TAIH04?
A5: It is widely used in power generation, oil and gas, chemical processing, pharmaceuticals, water treatment, and other process industries requiring reliable HART analog signal integration.
