ABB IMSET01 Sequence of Event Time Keeper Module

ABB IMSET01 Sequence of Event Time Keeper Module

Product Name: Sequence of Event Time Keeper Module

Brand Name: ABB

Model Number: IMSET01

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb imset01 sequence of event time keeper module-1

Overview
Connect With Us
Specifications
Alternative Name
Description
Functions
Advantage
Product Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Connect With Us

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	ABB IMSET01 Sequence of Event Time Keeper Module
Manufacturer	ABB
Product Type	Sequence of Event Time Keeper Module
Part Number	IMSET01
Weight	0.38kg
Estimated shipping dimensions	3.7x31.2x17.6cm
Place of shipment	Xiamen, China
Country of origin	Sweden
Timing Accuracy	±1 ms (with external synchronization)
Event Capture	Up to 16 digital inputs (24 V DC) with configurable debounce filters
Communication Protocols	Modbus RTU (RS-485), InfiNet (1 Mbps)
Power Supply	24 V DC (±15%), redundant inputs
Operating Temperature	-25°C to +70°C
Humidity	5–95% non-condensing
Certifications	CE, UL, ROHS

Alternative Name

IMSET01 SOE Time Synchronization Module

ABB IMSET01 Event Timestamping Module

IMSET01 Sequence of Events (SOE) Recorder Module

ABB Bailey Infi 90 IMSET01 Timing Module

IMSET01 Industrial Time Keeper Unit

ABB IMSET01 Event Synchronization Module

IMSET01 Digital Event Capture Module

ABB Symphony Plus IMSET01 SOE Module

IMSET01 Time Synchronization and Logging Module

Description

The ABB IMSET01 Sequence of Event Time Keeper Module is a high-precision timing and synchronization device designed for industrial automation systems. It is used to accurately record and timestamp sequence-of-events (SOE) such as alarms, breaker operations, and equipment status changes, ensuring precise event ordering in distributed control environments.

The module supports integration with ABB Bailey Infi 90 and Symphony Plus systems and captures up to 16 digital input signals with configurable filtering. It provides communication through Modbus RTU (RS-485) and InfiNet protocols, enabling reliable data transfer to control and monitoring systems.

It also supports external time synchronization sources including GPS, NTP, and IRIG-B, ensuring consistent and accurate time alignment across multiple controllers and plant-wide systems. The rugged industrial design, redundant power supply, and wide operating temperature range make it suitable for mission-critical applications.

Functions

Captures and timestamps industrial events with high precision
Supports up to 16 digital input channels (24 V DC)
Records sequence of events (SOE) for alarms and status changes
Synchronizes system time using GPS, NTP, or IRIG-B sources
Communicates with control systems via Modbus RTU and InfiNet protocols
Ensures unified time reference across distributed control systems
Applies debounce filtering for stable event detection

Advantage

High timing accuracy (±1 ms with external synchronization)
Reliable event sequencing for critical industrial processes
Supports multiple synchronization methods (GPS, NTP, IRIG-B)
Dual redundant power input for high system availability
Wide operating temperature range (-25°C to +70°C)
Robust industrial design suitable for harsh environments
Easy integration with ABB INFI 90 and Symphony Plus systems
Enhances system diagnostics and fault analysis capability
Complies with CE, UL, and RoHS standards
