⁠National Instruments PCI-5122 14-Bit PCI Oscilloscope Device Original new

⁠National Instruments PCI-5122 14-Bit PCI Oscilloscope Device Original new

Product Name:14-Bit PCI Oscilloscope Device

Brand Name:National Instruments

Model Number:PCI-5122

Country of Origin:USA

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

national instruments pci 5122 14 bit pci oscilloscope device original new-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	National Instruments
Model Number:	PCI-5122
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	PCI-5122
Product Type	High-Speed Digitizer Module
Number of Channels	2 Simultaneously Sampled Analog Input Channels
Input Connectors	BNC
Resolution	14-bit
Real-Time Sampling Rate	1.526 kS/s to 100 MS/s
Random Interleaved Sampling (RIS)	200 MS/s to 2 GS/s
Analog Bandwidth	100 MHz (80 MHz on 0.2 V range)
Input Impedance	Selectable 50 Ω ±2.0% or 1 MΩ ±0.75%
Input Coupling	AC, DC, GND (AC available on 1 MΩ input)
Full-Scale Input Ranges	0.2 V, 0.4 V, 1 V, 2 V, 4 V, 10 V, 20 V (1 MΩ only)
Maximum Input Overload	7 Vrms (50 Ω), ±42 V Peak (1 MΩ)
AC Amplitude Accuracy	±0.06 dB (50 Ω), ±0.09 dB (1 MΩ) at 50 kHz
Crosstalk	≤ -100 dB at 10 MHz
Rise/Fall Time	3.5 ns typical (4.2 ns on 0.2 V range)
Sample Clock Timebase	100 MHz
Sample Clock Jitter	≤1 ps RMS (100 Hz to 100 kHz)
Trigger Types	Edge, Window, Hysteresis, Video, Digital, Immediate, Software
Trigger Sources	CH0, CH1, TRIG, PXI Trigger, PFI, Software
Onboard Memory Options	8 MB, 64 MB, 256 MB
Maximum Records in Memory	Up to 100,000 Records
Calibration Interval	2 Years
Warm-Up Time	15 Minutes
Power Consumption	29.28 W Typical, 33.12 W Maximum
Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 71°C
Relative Humidity	10% to 90% Non-Condensing
Dimensions (W × H × D)	21.3 × 2.0 × 13.0 cm (8.4 × 0.8 × 5.1 in.)
Weight	453 g (16.0 oz)
Mounting Format	3U Single-Slot PXI Express Module
Software Support	NI-SCOPE, LabVIEW, LabWindows/CVI, Measurement Studio, .NET, Visual C/C++
Compliance Standards	IEC 61010-1, UL 61010-1, EN 61326-1, EN 55011, EN 55022
Application Category	High-Speed Data Acquisition, Signal Analysis, Automated Test and Measurement Systems

Description

The PCI-5122 high-speed digitizer is a precision data acquisition module engineered for advanced signal analysis, waveform capture, and automated test applications. Featuring dual simultaneously sampled analog input channels and 14-bit resolution, the PCI-5122 delivers accurate measurement performance for demanding laboratory, industrial, and research environments.

Designed with a maximum real-time sampling rate of 100 MS/s and bandwidth up to 100 MHz, the PCI-5122 enables reliable acquisition of fast-changing electrical signals. Its flexible input impedance selection, programmable vertical ranges, and advanced triggering capabilities allow engineers to perform detailed signal characterization across a wide variety of test scenarios.

The PCI-5122 is widely deployed in automated testing systems, industrial monitoring platforms, communications analysis, and electronic development applications. Its robust architecture, high dynamic performance, and compatibility with NI measurement software make it a trusted solution for precision data acquisition and waveform analysis.
