Product Name:SPEED DRIVE 100HP
Brand Name:Schneider
Model Number:ATV61HD75N4
Country of Origin:China
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Schneider |
Model Number: |
ATV61HD75N4 |
Country of Origin: |
SWEDEN |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | ATV61HD75N4 |
| Product Range | Altivar 61 |
| Rated Power | 75 kW / 100 hp |
| Supply Voltage | 380–480 V AC (3-phase) |
| Line Current | 137–167 A |
| Frequency Range | 0.1–500 Hz |
| EMC Filter | Level 3 integrated |
| Control Type | Sensorless vector / V/F control |
| Switching Frequency | 1–16 kHz adjustable |
| Protection Degree | IP20 / IP21 / IP54 (variant dependent) |
| Cooling Method | Heat sink cooling |
| Weight | 44 kg |
| Dimensions (W×H×D) | 320 × 630 × 290 mm |
The ATV61HD75N4 variable speed drive from the Altivar 61 series is engineered for efficient motor control in demanding pumping and ventilation systems. Designed for three-phase 380–480 V industrial power networks, it delivers stable performance for high-power applications up to 75 kW, supporting reliable process operation and optimized energy consumption in modern automation environments.
Built with advanced sensorless vector control and voltage/frequency regulation, the ATV61HD75N4 ensures smooth torque delivery and precise motor regulation under varying load conditions. It is compatible with both asynchronous and synchronous motors and supports multiple communication protocols including Modbus and CANopen for seamless system integration.
With integrated EMC filtering, robust protection functions, and flexible configuration options, the ATV61HD75N4 is suitable for harsh industrial installations requiring reliability, safety, and long-term operational stability across complex drive systems.
Q1: What is the main application of ATV61HD75N4?
A1: It is mainly used for pumps, fans, and ventilation systems in industrial automation.
Q2: What voltage range does ATV61HD75N4 support?
A2: It supports a three-phase 380–480 V AC power supply.
Q3: Does ATV61HD75N4 support vector control?
A3: Yes, it features sensorless flux vector control for precise motor performance.
Q4: Which communication protocols are available?
A4: It supports Modbus, CANopen, and optional fieldbus communication cards.
Q5: Is ATV61HD75N4 suitable for harsh environments?
A5: Yes, it includes EMC filtering and multiple protection features for industrial conditions.
