Siemens 6AV2124-0QC02-0AX2 SIMATIC HMI TP1500 Comfort Panel

Siemens 6AV2124-0QC02-0AX2 SIMATIC HMI TP1500 Comfort Panel

Product Name: SIMATIC HMI TP1500 Comfort Panel
Brand Name: Siemens
Model Number: 6AV2124-0QC02-0AX2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]

Appurtenance:

siemens 6av2124 0qc02 0ax2 simatic hmi tp1500 comfort panel-1

Overview
Commercial Term
Specifications
Contact info
Description
Function
About Company
Why Choose Us
Other Products
Recommended Products

SIEMENS INDUSTRIAL NETWORKING · SCALANCE XR SERIES

Siemens 6AV2124-0QC02-0AX2 SIMATIC HMI TP1500 Comfort Panel

15-inch Touch

Comfort Panel

Industrial HMI

Official Siemens product data identifies 6AV2124-0QC02-0AX2 as the SIMATIC HMI TP1500 Comfort Panel. The information below is organized for clear industrial sourcing and technical evaluation.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

TECHNICAL PARAMETER	OFFICIAL VALUE
Product type designation	TP1500 Comfort
Screen diagonal	15.4 in
Number of colors	16 777 216
Horizontal image resolution	1 280 pixel
Vertical image resolution	800 pixel
MTBF backlighting (at 25 °C)	80 000 h
Number of function keys	0
Direct keys (touch buttons as S7 input I/O)	40
maximum permissible angle of inclination without external	35°
Rated value (DC)	24 V
permissible range,	19.2 V–28.8 V
Current consumption (rated value)	1.7 A
Starting current inrush I²t	0.5 A²·s
Active power input, typ.	41 W
Processor type	X86
Memory available for user data	24 Mbyte
retentive	Yes; Back-up duration typically 6 weeks
Number of industrial Ethernet interfaces	2; 2 ports (switch) + independent port
Number of RS 485 interfaces	1; RS 422 / 485 combined
Number of RS 422 interfaces	0; together with RS 485
Number of RS 232 interfaces	0
Number of USB interfaces	2; USB 2.0
Number of 20 mA interfaces (TTY)	0
Number of parallel interfaces	0
Number of SD card slots	2
Industrial Ethernet status LED	3
Number of ports of the integrated switch	2
IRT	Yes; WinCC V14 SP1 HSP or higher
Diagnostic information readable	Yes; S7 controller
IP (at the front)	IP65
IP (rear)	IP20
For vertical installation,	0 °C–45 °C
At maximum tilt angle,	0 °C–40 °C
For vertical installation, max.	40 °C
Ambient temperature during storage/transportation	-20 °C–60 °C

Contact info

CONTACT

Sales
Jim Pei

Email
[email protected]

Phone/Whatsapp
+86 18020776782

Description

PRODUCT OVERVIEW · 6AV2124-0QC02-0AX2

6AV2124-0QC02-0AX2 is the Siemens SIMATIC HMI TP1500 Comfort Panel for professional industrial visualization. Its electrical, display, interface and environmental characteristics are summarized from the official Siemens data sheet. The panel supports dependable integration into compatible automation systems. It provides structured operator interaction and clear process monitoring. This Siemens HMI is suitable for replacement, modernization and new machine projects. Our team can support model confirmation before shipment.

Function

FUNCTION 01

Visualizes machine and process conditions for operators.

FUNCTION 02

Supports intuitive touch-based interaction with plant equipment.

FUNCTION 03

Displays alarms, trends and diagnostic information.

FUNCTION 04

Supports recipe handling and structured production workflows.

FUNCTION 05

Provides multilingual visualization for international installations.

FUNCTION 06

Integrates with Siemens automation systems.

FUNCTION 07

Helps operators monitor status and respond to process events.

FUNCTION 08

Supports commissioning, service and maintenance activities.
