Compact KTP400 Comfort operator panel combining function keys, resistive touch and industrial controller interfaces.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6AV2124-2DC01-0AX0
|
|
Display technology
|
TFT
|
|
Screen diagonal
|
4.3 in
|
|
Display resolution
|
480 × 272 pixels
|
|
Display colors
|
16,777,216
|
|
Backlight MTBF at 25 °C
|
80,000 h
|
|
Backlight dimming
|
0–100%
|
|
Function keys with LEDs
|
4
|
|
Touch technology
|
Analog-resistive
|
|
Direct touch keys as S7 input I/O
|
32
|
|
Maximum mounting inclination
|
35° without external ventilation
|
|
Rated supply voltage
|
24 V DC
|
|
Permitted supply range
|
19.2–28.8 V DC
|
|
Rated current consumption
|
0.13 A
|
|
Starting-current I²t
|
0.5 A²·s
|
|
Typical active power input
|
3.1 W
|
|
Processor architecture
|
ARM
|
|
User-data memory
|
4 Mbyte
|
|
Clock backup duration, typical
|
6 weeks
|
|
Industrial Ethernet interfaces
|
1
|
|
Combined serial interface
|
1 × RS422 / RS485
|
|
USB interface
|
1 × USB 2.0
|
|
USB Mini-B interface
|
1, 5-pole
|
|
SD card slots
|
2
|
|
Front protection
|
IP65; Enclosure Type 4 / 4X
|
|
Rear protection
|
IP20
|
|
Operating temperature, vertical landscape
|
0–50 °C
|
|
Operating temperature, vertical portrait
|
0–40 °C
|
|
Storage / transport temperature
|
-20 to +60 °C
|
|
Operating humidity, maximum
|
90%, non-condensing
|
|
Runtime languages
|
32
|
|
Bit messages
|
2,000
|
|
Analog messages
|
50
|
|
Minimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6AV2124-2DC01-0AX0 is a SIMATIC HMI KTP400 Comfort Panel for machine visualization. A widescreen TFT display combines analog-resistive touch with illuminated function keys. Industrial Ethernet and a combined serial interface connect the operator panel to supported controllers. User memory holds the configured visualization application. The panel is configured with the appropriate WinCC Comfort or higher engineering package.
The 6AV2124-2DC01-0AX0 provides a compact operator interface for process values, alarms and recipes. Physical function keys complement the touchscreen where direct operator actions are useful. Supported controller protocols allow integration into the intended machine network. Choose portrait or landscape mounting with the corresponding temperature limits. Verify the existing project, communication settings and required software version before commissioning or replacement.
Combines touch and physical function keys for the configured machine workflow.
Displays configured process values and operator input fields.
Supports the engineered alarm system and recipe management.
Controller integration — Connects to supported controllers through the selected industrial interface.
Project engineering — Use WinCC Comfort or the supported higher edition for the visualization project.
Panel replacement — Review mounting orientation, project backup and communication settings together.
No. The datasheet lists WinCC Comfort, Advanced or Professional from V11.
No. The panel has one Ethernet port and no integrated switch.
No. Select the permitted temperature for the actual mounting orientation.
Yes. Offered-unit photographs and available inspection details can be supplied.
Confirmed in-stock panels are arranged for dispatch immediately after payment.
Send the existing panel label, WinCC project version and controller connection details.
