Product Name: SIMATIC HMI OP3 Operator Panel
Brand Name: Siemens
Model Number: 6AV3503-1DB10
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6AV3503-1DB10 SIMATIC HMI OP3 Operator Panel |
| Manufacturer | Siemens |
| Product Type | SIMATIC HMI OP3 Operator Panel |
| Part Number | 6AV3503-1DB10 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Display Type | LC Display |
| Graphics Display | No |
| Display Color | Black/White |
| Display Lines | 2 |
| Characters per Line | 20 |
| Backlight MTBF | 200,000 h (at 25 °C) |
| Control Method | Keys |
| Keyboard Type | Membrane Keyboard |
| User-definable Keys | No |
| Function Keys | 5 |
| Maximum Installation Angle | 180° |
| Supply Voltage | 24 V DC |
| UPS Support | No |
| Current Consumption | 0.07 A |
| Processor | x86 |
| Storage Media | No Diskette Drive / No CD-ROM / No Hard Disk |
| Memory Type | Flash / RAM |
| User Memory | 128 KB |
| Backup Battery | No |
| Backup Time | 0 years |
| Clock Type | Software Clock (No Battery Backup) |
| Retentive Clock | No |
| Clock Synchronization | No |
| Communication Interfaces | 1 × RS232, 1 × RS485 |
| Maximum RS485 Transmission Rate | 1.5 Mbit/s |
| Front Protection Rating | IP65 |
| Rear Protection Rating | IP20 |
| Certifications | CE, GL, DNV, LRS, PRS, FM Class I Div.2, UL, CSA, cULus |
| Storage/Transport Temperature | -20 °C to +60 °C |
| Maximum Operating Humidity | 85% RH |
| Operating System | RMOS |
| Numeric Input | Yes |
| Alphabetical Input | No |
| Mounting Position | Vertical |
| Configuration Software | ProTool/Lite Version 2.51 or later (ordered separately) |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The Siemens 6AV3503-1DB10 SIMATIC HMI OP3 Operator Panel is a compact human-machine interface (HMI) designed for operator control and process visualization in SIMATIC automation systems. It features a 2-line black-and-white LC display, a membrane keyboard with five function keys, and RS232/RS485 communication interfaces for reliable interaction with compatible controllers and industrial equipment. Engineered for dependable operation in industrial environments, the operator panel provides a simple and efficient interface for monitoring machine status, entering operating commands, and managing production processes. Its compact design, robust construction, and seamless integration with Siemens automation systems make it an ideal choice for machine control, equipment operation, and industrial automation applications.
Compact Operator Interface
Provides an intuitive human-machine interface for machine operation, status monitoring, and process control.
2-Line LC Display
Features a black-and-white LCD with two lines of twenty characters for clear display of operating messages and system information.
Five Integrated Function Keys
Includes dedicated function keys and a durable membrane keyboard for reliable operator input.
24 V DC Power Supply
Operates from a standard 24 V DC industrial power source with low power consumption.
RS232 and RS485 Communication
Supports serial communication for reliable integration with compatible Siemens PLCs and automation devices.
Flash and RAM Memory
Utilizes Flash and RAM memory with 128 KB of user memory for storing operating data and application parameters.
Industrial Protection Design
Offers an IP65-rated front panel and IP20 rear protection, making it suitable for installation in industrial control cabinets.
Certified for Industrial Applications
Complies with multiple international certifications, including CE, UL, CSA, FM, GL, DNV, LRS, and PRS, ensuring reliable operation in demanding industrial environments.
✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems
