Key-operated OP27 panel with monochrome STN graphics, configurable function keys and serial PLC interfaces.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6AV3627-1JK00-0AX0
|
|
Display technology
|
STN, 8 gray scales
|
|
Screen diagonal
|
5.7 in
|
|
Display resolution
|
240 × 320 pixels
|
|
Backlight MTBF at 25 °C
|
50,000 h
|
|
Function keys
|
24
|
|
Function keys with LEDs
|
18
|
|
Permitted mounting inclination
|
35° without external ventilation
|
|
Rated current consumption
|
0.3 A
|
|
Typical power consumption
|
8 W
|
|
Processor
|
X86, 33 MHz
|
|
Usable user-data memory
|
1,024 kbyte
|
|
Memory technology
|
Flash / RAM
|
|
Optional backup battery
|
3.6 V
|
|
Minimum backup time
|
4 years
|
|
TTY interfaces
|
1
|
|
RS232 interfaces
|
2
|
|
RS422 interfaces
|
1
|
|
RS485 interfaces
|
1
|
|
RS485 transmission rate, maximum
|
12 Mbit/s
|
|
PC card slots
|
1
|
|
Front protection
|
IP65
|
|
Rear protection
|
IP20
|
|
Storage / transport temperature
|
-20 to +60 °C
|
|
Operating relative humidity, maximum
|
95%
|
|
Configuration software
|
ProTool V3.1 or higher
|
|
Operating system
|
Rmos
|
|
Input method
|
Membrane keys, numeric / alphabetic / hexadecimal
|
|
Clock
|
Battery-backed, retentive, synchronizable hardware clock
|
|
Touchscreen
|
Not fitted
|
|
Industrial Ethernet interface
|
Not fitted
|
|
Minimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6AV3627-1JK00-0AX0 is a SIMATIC OP27 operator panel with monochrome STN graphics. The display presents process information in gray scales. A membrane keyboard combines function keys with numeric and alphabetic entry. Integrated LEDs provide feedback on selected key functions. Serial interfaces connect the panel to the intended automation system.
The 6AV3627-1JK00-0AX0 supports operator interaction in established SIMATIC machine installations. ProTool is used to configure the compatible visualization project. Its hardware clock can retain time using the optional backup arrangement. Existing project files, serial wiring and controller settings should be reviewed before replacement. This panel uses physical keys rather than a touchscreen, so the original operating concept should be preserved.
Provides key-based operation for established machine visualization projects.
Links the panel to compatible controllers through its serial interfaces.
Presents the configured operator information on the monochrome graphics display.
Project migration check — Review the original ProTool project before selecting a replacement.
Keyboard matching — Check function-key labeling and intended LED assignments.
Backup planning — Verify battery condition where retained time is required.
No. This OP27 variant is operated with physical membrane keys.
Use ProTool V3.1 or higher as specified for this panel.
Do not assume this; its controller interfaces are serial and project compatibility must be checked.
Yes. Ask for photographs, condition details and available inspection information.
Confirmed in-stock units are arranged for immediate dispatch after receipt of payment.
Yes. The full label and existing project information help identify the correct replacement.
