Product Name: SIMATIC ITP1000 Industrial Tablet PC
Brand Name: Siemens
Model Number: 6AV7880-0AA21-0AA2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6AV7880-0AA21-0AA2 |
| Horizontal image resolution | 1 280 pixel; 1 920 pixels |
| Vertical image resolution | 800 pixel; 1 200 pixels |
| Design of the power supply | External wide-range power supply; 3-pole |
| permissible range, lower limit (AC) | 100 V; ±10 %, sinusoidal |
| permissible range, upper limit (AC) | 240 V; ±10 %, sinusoidal |
| permissible range, lower limit | 47 Hz |
| permissible range, upper limit | 63 Hz |
| Memory capacity | 256 Gbyte; Up to 512 GB SSD |
| Type of memory | DDR4-SDRAM SO-DIMM |
| integrated | 4 Gbyte; 8 GB or 16 GB |
| DisplayPort | Yes; DP 1.2 (Mini DisplayPort) |
| Protocol for wireless transmission | Legic Prime, Legic Advant, ISO 15693, ISO 14443 A/B |
| Operating frequency (rated value) | 13.56 MHz |
| Range, max. | 30 mm; Range depends on transponder |
| IP degree of protection | IP40 |
| Processor type | Celeron G3902 (2C/2T, 1.6 GHz, 2 MB cache); Intel Core i5-6442EQ (6 MB |
| Graphics controller | Intel® HD graphics 530 |
| Capacity | 5 900 mA·h |
| Battery runtime, min. | 6 h; According to MobileMark 2014 |
| Bluetooth radio standard | Yes; V4.0 |
| Universal Audio Jack | Yes; Audio socket for 3.5 mm jack |
| Type | IEEE 802.11 a/b/g/n and ac |
| Interference immunity against discharge of static | Yes; ±4 kV contact discharge (to IEC 801-2/IEC 1000-4-2; ESD), ±8 kV air |
| electricity acc. to IEC 61000-4-2 | discharge (to IEC 801-2/IEC 1000-4-2; ESD) |
| min. | 5 °C; Max. 10 °C/h (no condensation) |
| max. | 45 °C; Max. 10 °C/h (no condensation) |
| Operation, min. | 5 %; At 30 °C/h (no condensation); Tested according to IEC 60068-2-78, IEC |
| Operation, max. | 85 %; At 30 °C/h (no condensation); Tested according to IEC 60068-2-78, IEC |
| Local language of operating system | Multi-Language User Interface (MUI): 6 languages (English, German, French, |
| Windows 7 | Yes; Ultimate 64 bit, SP1 |
| Windows 10 | Yes; Windows 10 Enterprise 2016 LTSB, 64 bit, MUI |
| Number of industrial Ethernet interfaces | 1 |
| Number of RS 232 interfaces | 1 |
| Number of USB interfaces | 3; USB 3.0 |
|
01
6AV7880-0AA21-0AA2 is suitable for mobile industrial visualization, commissioning, diagnostics, service, maintenance, and digital work instructions. |
02
It can also support wireless plant access, machine-side engineering, data acquisition, and field-service workflows. |
|
