Product Name: SIMATIC TDC SB70 Binary Output Module
Brand Name: Siemens
Model Number: 6DD1681-0AG2
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Product Name | Siemens 6DD1681-0AG2 SIMATIC TDC SB70 Binary Output Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC TDC SB70 Binary Output Module |
| Part Number | 6DD1681-0AG2 |
| Weight | 0.36kg |
| Estimated shipping dimensions | 4.5x15.9x12.9cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product Model | SB70 |
| Output Type | Relay Outputs |
| Number of Digital Inputs | 0 |
| Number of Digital Outputs | 8 |
| Output Voltage | DC/AC, max. 120 V |
| Display | LED indication |
| Connection Cable | SC62 |
| Compatible Systems | SIMATIC TDC / FM458-1DP |
| LED Indicators | Yes |
| Electrical Isolation | Yes |
| Primary Function | Binary Output Module |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
Reliable Relay Output Control
Provides 8 relay output channels for dependable switching of field devices, actuators, and industrial equipment in demanding automation applications.
Designed for SIMATIC TDC Systems
Fully compatible with SIMATIC TDC and FM458-1DP platforms, enabling seamless integration into existing automation and drive control systems.
Clear LED Status Indication
Equipped with LED indicators that display the operating status of each output channel, allowing maintenance personnel to quickly verify system operation and identify faults.
Electrical Isolation for Improved Reliability
Features electrical isolation between control and field circuits to enhance signal integrity, reduce electrical interference, and improve overall system stability.
Simple Installation and Maintenance
Supports SC62 connection cables for convenient wiring and efficient module replacement, helping reduce installation time and maintenance effort.
Ideal for Industrial Automation
Suitable for process automation, power generation, industrial drive systems, manufacturing equipment, and other applications requiring reliable binary output control.
Q1: What is the 6DD1681-0AG2 used for?
A: The 6DD1681-0AG2 is a binary output module used to control relay-based output signals for field devices and industrial equipment in SIMATIC TDC and FM458-1DP automation systems.
Q2: How many output channels does the 6DD1681-0AG2 provide?
A: The 6DD1681-0AG2 provides 8 relay output channels for reliable switching and control of external devices.
Q3: Does the 6DD1681-0AG2 support LED status indication?
A: Yes. The 6DD1681-0AG2 includes integrated LED indicators that provide clear visual feedback on the operating status of each output channel.
Q4: Is the 6DD1681-0AG2 electrically isolated?
A: Yes. The 6DD1681-0AG2 features electrical isolation to improve system reliability, enhance noise immunity, and protect connected control circuits.
Q5: Which systems are compatible with the 6DD1681-0AG2?
A: The 6DD1681-0AG2 is compatible with SIMATIC TDC and FM458-1DP automation platforms, making it suitable for a wide range of industrial control applications.
Q6: Which industrial applications are suitable for the 6DD1681-0AG2?
A: The 6DD1681-0AG2 is widely used in power generation, process automation, manufacturing, industrial drive systems, and other applications requiring dependable binary output control.
