Siemens 6DD1688-0AE2 SS52 communication module Original new

Siemens 6DD1688-0AE2 SS52 communication module Original new

Product Name:SS52 communication module

Brand Name:Siemens

Model Number:6DD1688-0AE2

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6dd1688 0ae2 ss52 communication module original new-1

Overview
Get your discount today
Specifications
Description
Applications
Environment and Certification
Features and Benefits
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6DD1688-0AE2
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model:	6DD1688-0AE2 Siemens SS52 communication module designed for SIMADYN D industrial communication and PROFIBUS networking.
Product Type:	SS52 Communication Module for CS7 support module.
System Compatibility:	Compatible with Siemens SIMADYN D automation systems and CS7 support modules.
Communication Protocols:	Supports PROFIBUS-DP, PROFIBUS-FMS (SINEC L2-FMS), and MPI communication.
Operating Mode:	Configurable as PROFIBUS master or slave with shared input, SYNC, FREEZE, and direct slave-to-slave communication functions.
Diagnostic Interface:	Integrated RS-232 interface for parameterization, diagnostics, and database downloading using COM PROFIBUS software.
Electrical Features:	Electrically isolated RS-485 PROFIBUS interface with integrated 5 V supply for Optical Link Modules (OLM).
Installation:	Plug-in module mounted on Siemens CS7 communication support module with dual-port RAM data exchange.
Dimensions:	70 × 184 × 22 mm (W × H × D).
Weight:	Approx. 0.2 kg.

Description

6DD1688-0AE2 is a Siemens SS52 communication module engineered for the SIMADYN D automation platform, providing reliable PROFIBUS-DP, PROFIBUS-FMS, and MPI communication for advanced industrial control systems. Installed on the CS7 support module, it enables high-speed data exchange between CPU modules and distributed field devices, ensuring stable communication in demanding automation environments.

Designed for flexible network integration, 6DD1688-0AE2 supports master and slave operation on PROFIBUS-DP, direct slave-to-slave communication, SYNC/FREEZE functions, and RS-232 parameterization for diagnostics and commissioning. Compared with 6DD1688-0AE0 (SS5), the SS52 version offers enhanced configuration capabilities and simplified database downloading through COM PROFIBUS software.

Suitable for power generation, metallurgy, transportation, and process industries, 6DD1688-0AE2 delivers dependable industrial networking, efficient diagnostics, and long-term operational stability. Its robust Siemens design, isolated PROFIBUS interface, and seamless integration with SIMADYN D systems make it an ideal communication solution for legacy automation maintenance and modernization projects.

Applications

Power plants: Provides reliable PROFIBUS communication for turbine controllers, generator monitoring, and distributed process automation.
Substations: Enables real-time communication between protection relays, intelligent electronic devices, and supervisory control systems.
Chemical plants: Integrates distributed controllers, process instrumentation, and industrial field devices through stable PROFIBUS networking.
Steel mills: Supports high-speed communication for rolling mills, motor drives, and coordinated production control under demanding operating conditions.
Machinery manufacturing plants: Connects PLCs, HMIs, robots, and automation equipment for synchronized production line communication.
Oil & gas facilities: Supports distributed process control, field communication, and intelligent instrumentation networks.
Water treatment plants: Provides dependable communication between controllers, sensors, valves, and remote automation equipment.

Environment and Certification

Designed for continuous operation in industrial communication networks.
Manufactured according to Siemens industrial automation quality standards.
Electrically isolated PROFIBUS interface improves communication reliability.
Suitable for demanding factory environments with industrial electromagnetic conditions.
Supports long-term operation within SIMADYN D control architectures.
Rugged mechanical construction enhances service life and operational stability.
Engineered for reliable communication in mission-critical industrial applications.

Features and Benefits

Supports PROFIBUS-DP, PROFIBUS-FMS, and MPI communication on a single module.
Configurable as both PROFIBUS master and slave for flexible network architecture.
Direct slave-to-slave communication improves system efficiency and reduces controller workload.
Integrated RS-232 interface simplifies commissioning, diagnostics, and maintenance.
Electrical isolation enhances network stability and protects communication circuits.
Compact plug-in design allows quick installation and convenient module replacement.
LED diagnostics provide clear operating status and fault indication.
Seamless compatibility with Siemens SIMADYN D systems simplifies modernization of existing automation installations.

FAQ

Q1: What is 6DD1688-0AE2 used for?
A1: 6DD1688-0AE2 is a Siemens SS52 communication module that enables PROFIBUS-DP, PROFIBUS-FMS, and MPI communication in SIMADYN D automation systems.

Q2: Which communication protocols are supported by 6DD1688-0AE2?
A2: The module supports PROFIBUS-DP, PROFIBUS-FMS (SINEC L2-FMS), and MPI communication for industrial networking applications.

Q3: Can 6DD1688-0AE2 operate as both a master and a slave?
A3: Yes. It supports both master and slave operating modes on PROFIBUS-DP, including SYNC, FREEZE, shared input, and direct slave-to-slave communication.

Q4: What are the dimensions and weight of 6DD1688-0AE2?
A4: The module measures 70 × 184 × 22 mm and weighs approximately 0.2 kg.

Q5: Why choose 6DD1688-0AE2 for industrial communication systems?
A5: Its multi-protocol support, isolated PROFIBUS interface, integrated diagnostics, flexible master/slave operation, and proven Siemens reliability make it an excellent solution for maintaining and expanding SIMADYN D industrial automation networks.
