Bently Nevada 330909-00-60-10-02-05 3300 NSv Proximity Probes Ready For Ship

Bently Nevada 330909-00-60-10-02-05 3300 NSv Proximity Probes Ready For Ship

Product Name:3300 NSv Proximity Probes

Brand Name:Bently Nevada

Model Number:330909-00-60-10-02-05

Country of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

bently nevada 330909 00 60 10 02 05 3300 nsv proximity probes ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Bently Nevada
Model Number:	330909-00-60-10-02-05
Country of Origin:	USA
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Specification Item	Details
Product Model	330909-00-60-10-02-05
Product Series	3300 XL NSv Proximity Probe
Thread Type	3/8-24 UNF
Cable Type	Armored coaxial cable
Total Length	1.0 meter (39 in)
Output Sensitivity	7.87 V/mm (200 mV/mil)
Linear Range	1.5 mm (60 mils)
Frequency Response	0 to 10 kHz
Probe Material	AISI 304 stainless steel
Probe Tip Material	Polyphenylene sulfide (PPS)
Operating Temperature	-52°C to +177°C
Connector Type	Miniature coaxial ClickLoc
Protection Rating	High EMI/RFI immunity
Dimension	118x1.5x1.2cm
Weight	0.16kg
Compliance	CE, RoHS, ATEX, IECEx, SIL 2/SIL 3

Description

The Bently Nevada 330909-00-60-10-02-05 proximity probe is engineered for high-precision shaft vibration and axial position monitoring in compact rotating machinery applications. As part of the 3300 XL NSv transducer family, this model delivers stable eddy-current sensing performance for centrifugal compressors, turbines, pumps, and high-speed industrial equipment operating in demanding process environments.

Designed with a rugged armored cable structure and advanced electromagnetic interference resistance, 330909-00-60-10-02-05 ensures dependable signal transmission in installations where space is limited and mechanical reliability is critical. Compared with earlier 3300 RAM and traditional 5 mm or 8 mm systems, the 3300 XL NSv series offers improved side-view capabilities and optimized performance for smaller shaft diameters.

The combination of stainless-steel construction, ClickLoc connectors, and enhanced chemical resistance makes 330909-00-60-10-02-05, 330901, and 330902 suitable for continuous machinery protection systems across power generation, oil & gas, petrochemical, and manufacturing industries. Its compact design simplifies integration into modern condition monitoring and predictive maintenance platforms.

Applications

Power plants: Used for turbine shaft vibration monitoring and rotating equipment protection systems.
Substations: Support auxiliary rotating machinery condition monitoring and predictive maintenance programs.
Chemical plants: Suitable for compressors and process gas equipment operating in corrosive environments.
Steel mills: Provide stable vibration measurement in high-temperature and strong EMI industrial areas.
Machinery manufacturing plants: Applied in automated rotating equipment diagnostics and balancing systems.
Oil & gas facilities: Monitor centrifugal compressors and high-speed pumps in critical process units.
Marine systems: Used in shipboard rotating machinery and offshore platform monitoring systems.

Features

Compact probe design for tight installation spaces
Excellent EMI and RFI resistance performance
Armored cable construction for harsh environments
High-accuracy eddy current sensing technology
Compatible with 3300 XL NSv monitoring systems
Durable stainless-steel probe housing
Stable long-distance signal transmission
Supports DIN-rail and panel-mounted systems

Functions

Measures shaft radial vibration accurately
Detects axial thrust position variations
Provides continuous machinery condition feedback
Supports predictive maintenance strategies
Enables high-speed rotating equipment diagnostics
Assists machinery protection and alarm systems
Improves operational reliability and equipment safety

FAQ

Q1: What is the main use of 330909-00-60-10-02-05?
A1: It is mainly used for shaft vibration and axial position monitoring in rotating machinery.

Q2: Is 330909-00-60-10-02-05 suitable for compact installations?
A2: Yes, the NSv series is specifically designed for limited-space machinery applications.

Q3: Can this probe operate in harsh industrial environments?
A3: Yes, it features armored cable protection and strong EMI resistance for demanding conditions.

Q4: Which systems are compatible with this proximity probe?
A4: It works with Bently Nevada 3300 XL NSv Proximitor sensors and monitoring systems.

Q5: Does the probe support hazardous area applications?
A5: Yes, the product supports ATEX and IECEx certified installations when properly configured.

Spares

Number	Describe
147357	3300 XL NSv Proximitor User Guide
02120015	Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire
138492-01	Replacement panel-mount mounting pad
138493-01	Replacement DIN-mount mounting pad
01609137	BNC (F) to banana plugs adapter
01609138	Proximitor connector test pin wiring with two test pins and BNC (F) connector
40971-04	50 Ω cable with dual BNC (M) connectors for transducer system performance testing
04310310	3300 XL Proximitor Sensor panel-mount screws package
03200006	Silicone self-fusing tape for connector insulation and environmental protection
40113-03	Connector Protector Kit for 3300 NSv probes and extension cables
136536-01	Connector Protector Adapter for pre-1998 installation tools
40180-03	Connector protectors package containing 10 pairs
03800000	Male connector protector for extension cable environmental protection
03800001	Female connector protector for probe lead and Proximitor Sensor connection
330153-05	3300 NSv Connector Kit with ClickLoc connectors, sleeves, and silicone tape
