Product Name:ELECTRONIC MODULE DIGITAL
Brand Name:Siemens
Model Number:6ES7131-0BH00-0XB0
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7131-0BH00-0XB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Specification |
|---|---|
| Model | 6ES7131-0BH00-0XB0 |
| Product Series | SIMATIC ET 200B |
| Product Type | Digital Input Module |
| Number of Inputs | 16 Digital Inputs |
| Input Voltage | 24 V DC |
| Input Current | Typical 4 mA at 24 V |
| Signal Voltage "0" | -30 V to +5 V |
| Signal Voltage "1" | 13 V to 30 V |
| Input Delay | 2 to 3.5 ms |
| Communication Protocol | PROFIBUS DP |
| Maximum Transmission Rate | 12 Mbit/s |
| Cable Length | Up to 100 m (Unshielded) |
| Protection Rating | IP20 |
| Operating Temperature | 0°C to +60°C |
| Dimensions (W × H × D) | 160 × 130 × 60 mm |
| Weight | Approx. 600 g |
6ES7131-0BH00-0XB0 is a Siemens SIMATIC ET 200B digital input module developed for dependable signal acquisition in distributed automation systems. Featuring 16 digital inputs operating at 24 V DC, the module efficiently captures field device status information and transfers it to higher-level control systems through the PROFIBUS DP network.
Designed for industrial environments, 6ES7131-0BH00-0XB0 combines stable signal processing, fast response characteristics, and robust diagnostic capabilities. Its compact ET 200B architecture allows seamless integration into decentralized I/O installations while supporting reliable communication with SIMATIC automation platforms.
Widely implemented in manufacturing, utilities, process industries, and infrastructure projects, 6ES7131-0BH00-0XB0 helps improve operational visibility, supports real-time monitoring of digital signals, and enhances overall control system performance in demanding automation applications.
Power Plants: Collects digital status signals from generators, switchgear, and protection systems, enabling reliable monitoring and automation control.
Substations: Acquires field device status information, supports relay monitoring, line protection systems, and SCADA data collection.
Chemical Plants: Integrates sensors and switches into process automation systems, supporting safe and efficient plant operations.
Steel Mills: Monitors equipment status signals in harsh industrial environments, ensuring reliable operation under vibration and electromagnetic interference.
Machinery Manufacturing Plants: Connects limit switches, proximity sensors, and control devices, supporting automated production lines and robotic systems.
Water Treatment Facilities: Captures digital process signals from pumps, valves, and monitoring equipment, improving operational efficiency and control.
16-Channel Digital Input Design – Supports simultaneous acquisition of multiple 24 V DC field signals, improving monitoring efficiency.
PROFIBUS DP Communication – Enables reliable high-speed data exchange, supports distributed automation architectures.
Fast Signal Response – Provides rapid input processing, improves control accuracy, enhances system responsiveness.
Integrated Diagnostic Indicators – Includes RUN, BF, and input status LEDs, simplifying troubleshooting and maintenance.
Industrial-Grade Construction – Designed for continuous operation in demanding industrial environments, ensuring long-term reliability.
Digital Signal Acquisition Function – Collects ON/OFF status signals from sensors and field devices, enabling accurate process monitoring.
Data Communication Function – Transfers input data through PROFIBUS DP networks, supporting real-time automation control.
Status Monitoring Function – Tracks equipment operating conditions, improving visibility across industrial processes.
Diagnostic Function – Provides fault and communication status indication, helping reduce maintenance time and system downtime.
Distributed I/O Function – Extends automation systems with decentralized input capabilities, increasing flexibility and scalability.
Q1: What is the Siemens 6ES7131-0BH00-0XB0 used for?
A1: It is a 16-channel digital input module used for acquiring 24 V DC field signals in ET 200B distributed I/O systems.
Q2: How many digital inputs are available on the module?
A2: The module provides 16 digital input channels for industrial automation applications.
Q3: Which communication protocol does the 6ES7131-0BH00-0XB0 support?
A3: It communicates through the PROFIBUS DP network for reliable distributed control integration.
Q4: What input voltage is required for this module?
A4: The module is designed for standard 24 V DC digital input signals.
Q5: Where is the 6ES7131-0BH00-0XB0 commonly used?
A5: It is widely used in power generation, manufacturing, process industries, water treatment, and industrial automation systems.
|
