Product Name: SIMATIC DP ET 200L 16-Channel Digital Input Electronic Block
Brand Name: Siemens
Model Number: 6ES7131-1BH01-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7131-1BH01-0XB0 SIMATIC DP ET 200L 16-Channel Digital Input Electronic Block |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200L 16-Channel Digital Input Electronic Block |
| Part Number | 6ES7131-1BH01-0XB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Supply Voltage | 24 V DC |
| Load Voltage (L+) | 24 V DC (1L+, 2L+, 3L+) |
| Reverse Polarity Protection | Yes |
| Power Failure Buffer Time | 20 ms |
| Maximum Input Current | 70 mA (Supply Voltage L+) |
| Load Current Consumption | Max. 50 mA per Load Group |
| Typical Power Loss | 2.2 W |
| Required Terminal Block | TB 16L |
| Number of Digital Inputs | 16 |
| Rated Input Voltage | 24 V DC |
| Signal "0" Voltage | -30 to +5 V |
| Signal "1" Voltage | +13 to +30 V |
| Input Current ("1") | Typical 5 mA |
| Input Current ("0") | Max. 1.5 mA |
| Input Delay (0 → 1) | 2 to 4.5 ms |
| Input Delay (1 → 0) | 2 to 4.5 ms |
| Maximum Shielded Cable Length | 1,000 m |
| Maximum Unshielded Cable Length | 600 m |
| Supported Sensors | 2-wire Sensors |
| Maximum Transmission Rate | 1.5 Mbit/s |
| Isolation Voltage | 500 V DC |
| Degree of Protection | IP20 |
| Operating Temperature | 0 to +60 °C (Horizontal Installation); +40 °C for Other Mounting Positions |
| Permissible Air Pressure | 795 to 1080 hPa |
| Operating Humidity | 5% to 95% RH (IEC 61131-2, RH Class 2) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7131-1BH01-0XB0 SIMATIC DP ET 200L 16-Channel Digital Input Electronic Block is a 16-channel 24 V DC digital input module designed for the SIMATIC DP ET 200L distributed I/O system. It provides reliable digital signal acquisition from field devices and supports 2-wire sensors for flexible industrial applications. Featuring reverse polarity protection, 500 V DC isolation, long cable support, and fast input response times, the module delivers dependable performance in factory automation environments.
Compared with similar digital input modules, the Siemens 6ES7131-1BH01-0XB0 offers high channel density, reliable signal processing, and seamless integration with ET 200L systems.
Q1: What is the 6ES7131-1BH01-0XB0 used for?
A1: 6ES7131-1BH01-0XB0 is used to acquire digital input signals from field devices in SIMATIC DP ET 200L distributed I/O systems.
Q2: How many digital inputs does the 6ES7131-1BH01-0XB0 provide?
A2: 6ES7131-1BH01-0XB0 provides 16 digital input channels.
Q3: What is the rated input voltage of the 6ES7131-1BH01-0XB0?
A3: 6ES7131-1BH01-0XB0 is designed for 24 V DC digital input signals.
Q4: Does the 6ES7131-1BH01-0XB0 support 2-wire sensors?
A4: 6ES7131-1BH01-0XB0 supports the direct connection of 2-wire sensors.
Q5: What terminal block is required for the 6ES7131-1BH01-0XB0?
A5: 6ES7131-1BH01-0XB0 requires the TB 16L terminal block for installation.
Q6: What is the maximum communication speed of the 6ES7131-1BH01-0XB0?
A6: 6ES7131-1BH01-0XB0 supports a maximum transmission rate of 1.5 Mbit/s.
