Product Name: Digital Input Module
Brand Name: SIEMENS
Model Number: 6ES7131-4BD01-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7131-4BD01-0AB0 Digital Input Module |
| Manufacturer | SIEMENS |
| Product Type | Digital Input Module |
| Part Number | 6ES7131-4BD01-0AB0 |
| Weight | 0.04kg |
| Estimated shipping dimensions | 8.5x5.5x1.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Series | ET 200S |
| Digital Inputs | 4 DI |
| Input Voltage | 24 VDC |
| Width | 15 mm |
| Parameterization | Input Delay Configurable |
| Diagnostics | Supported |
| Short-Circuit Detection | Supported |
| LED Indicator | SF (System Fault) LED |
| Siemens ET 200S Module | ET200S Digital Input Card |
| PLC Input Module | PLC Expansion Module |
| Industrial Input Interface | Industrial Monitoring Module |
| Distributed I/O Module | Sensor Interface Module |
| Automation Input Module | Compact I/O Module |
| Siemens PLC Hardware | Siemens Automation Hardware |
| Digital Signal Acquisition Module | Distributed Control System Module |
| Industrial Control Module | Industrial Electronics Module |
| Factory Automation Component | Field Signal Input Module |
The 6ES7131-4BD01-0AB0 is a compact digital input module designed for Siemens ET 200S distributed I/O systems. It provides four digital input channels for acquiring field signals from sensors, switches, pushbuttons, and other industrial devices.
Featuring configurable input delay, integrated diagnostics, and short-circuit detection, the module ensures reliable signal processing and enhanced system monitoring. Its slim 15 mm design makes it ideal for space-constrained industrial automation applications.
Digital Signal Acquisition
Collects digital input signals from sensors, switches, and field devices for PLC processing.
4-Channel Input Processing
Provides four independent digital input channels for monitoring machine and process conditions.
24 VDC Input Support
Accepts standard 24 VDC industrial input signals for broad application compatibility.
Configurable Input Delay
Allows parameterized input delay settings to filter unwanted signal fluctuations.
Diagnostic Monitoring
Supports built-in diagnostics for improved fault detection and system reliability.
Short-Circuit Detection
Monitors input circuits and identifies potential short-circuit conditions.
Status Indication
Includes an SF (System Fault) LED for quick visual fault identification.
Distributed I/O Integration
Integrates seamlessly with Siemens ET 200S distributed automation systems.
Compared with similar digital input modules, the 6ES7131-4BD01-0AB0 offers advanced diagnostics, configurable signal filtering, and a compact design, making it an efficient solution for distributed automation systems.
Compact 15 mm Width: Saves valuable control cabinet space while maintaining full functionality.
Configurable Input Delay: Improves signal stability by filtering noise and transient inputs.
Integrated Diagnostics: Enhances troubleshooting and reduces system downtime.
Short-Circuit Detection: Provides additional protection and fault monitoring capabilities.
Reliable 24 VDC Operation: Compatible with standard industrial sensors and switches.
Easy ET 200S Integration: Designed specifically for Siemens distributed I/O architectures.
Visual Fault Indication: SF LED enables rapid identification of system issues.
How many input channels does 6ES7131-4BD01-0AB0 provide?
The 6ES7131-4BD01-0AB0 provides four digital input channels.
What input voltage does 6ES7131-4BD01-0AB0 support?
The 6ES7131-4BD01-0AB0 operates with standard 24 VDC input signals.
Does 6ES7131-4BD01-0AB0 support diagnostics?
Yes, the 6ES7131-4BD01-0AB0 includes integrated diagnostic functions for system monitoring.
Can 6ES7131-4BD01-0AB0 detect short circuits?
Yes, the 6ES7131-4BD01-0AB0 supports short-circuit detection for enhanced protection and fault identification.
What is the purpose of the SF LED on 6ES7131-4BD01-0AB0?
The 6ES7131-4BD01-0AB0 uses the SF LED to indicate system faults and diagnostic events.
Which automation platform is 6ES7131-4BD01-0AB0 designed for?
The 6ES7131-4BD01-0AB0 is designed for Siemens ET 200S distributed I/O systems.
