Product Name: SIMATIC ET 200S Digital Input Module
Brand Name: Siemens
Model Number: 6ES7131-4FB00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7131-4FB00-0AB0 SIMATIC ET 200S Digital Input Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC ET 200S Digital Input Module |
| Part Number | 6ES7131-4FB00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Input Voltage | 230 VAC |
| Allowable Input Range | 192–264 VAC |
| Backplane Bus Power Supply | 3.3 VDC |
| Backplane Bus Current | Maximum 6 mA |
| Typical Power Consumption | 0.7 W |
| Number of Input Points | 2 |
| Input Type | AC |
| Rated Input Voltage | 230 VAC |
| OFF State (Logic 0) | 0–40 VAC |
| ON State (Logic 1) | 164–264 VAC |
| Input Frequency | 47–63 Hz |
| Typical Input Current in ON State | 5 mA (Range 5–15 mA) |
| Shielded Cable | 1000 m |
| Unshielded Cable | 600 m |
| Maximum Potential Difference between Input and Internal M | 1500 VAC |
| Withstand Voltage Test | 4000 VDC |
| Two-Wire Sensor Allowable Static Current | ≤2 mA |
| Packing Mode | 2 bit |
| Unpacked Mode | 1 Byte |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The 6ES7131-4FB00-0AB0 SIMATIC ET 200S Digital Input Module is a compact AC digital input module designed for the Siemens ET 200S distributed I/O system. It provides two 230 VAC digital input channels for monitoring AC control signals from switches, push buttons, relays, and other field devices. With reliable signal detection, high electrical isolation, and seamless integration into ET 200S systems, the module is well suited for industrial automation, machine control, and process monitoring applications.
✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems
Q1: What is the 6ES7131-4FB00-0AB0 SIMATIC ET 200S Digital Input Module used for?
A: The 6ES7131-4FB00-0AB0 is used to monitor 230 VAC digital signals from field devices and transmit their status to Siemens ET 200S automation systems.
Q2: How many input channels does the 6ES7131-4FB00-0AB0 provide?
A: The 6ES7131-4FB00-0AB0 provides two AC digital input channels.
Q3: What input voltage does the 6ES7131-4FB00-0AB0 support?
A: The 6ES7131-4FB00-0AB0 is designed for a rated input voltage of 230 VAC and supports an allowable input range of 192–264 VAC.
Q4: What input frequency does the 6ES7131-4FB00-0AB0 support?
A: The 6ES7131-4FB00-0AB0 supports AC input frequencies from 47 Hz to 63 Hz.
Q5: What are the ON and OFF input voltage ranges of the 6ES7131-4FB00-0AB0?
A: The 6ES7131-4FB00-0AB0 recognizes OFF-state signals from 0–40 VAC and ON-state signals from 164–264 VAC.
Q6: What cable lengths are supported by the 6ES7131-4FB00-0AB0?
A: The 6ES7131-4FB00-0AB0 supports shielded cables up to 1000 meters and unshielded cables up to 600 meters.
