Product Name: SIMATIC DP ET 200B Digital Electronic Module
Brand Name: Siemens
Model Number: 6ES7132-0BH11-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7132-0BH11-0XB0 SIMATIC DP ET 200B Digital Electronic Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200B Digital Electronic Module |
| Part Number | 6ES7132-0BH11-0XB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Outputs | 16 DO |
| Output Rating | 24 V DC / 2 A |
| Degree of Protection | IP20, according to EN 60529 |
| Rated Supply Voltage | 24 V DC (L1+, L2+, L3+, L4+, L5+) |
| Temporary Voltage | 35 V at t < 0.5 s |
| Permissible Supply Voltage Range | 18.5–30.2 V DC |
| Typical Current Consumption | 100 mA from L5+ (logic) |
| I²t | 0.05 A²·s, including starting inrush current |
| Maximum Power Loss | 7 W |
| Short-Circuit Protection | Yes, electronic |
| Inductive Shutdown Voltage Limitation | Typically -50 V (L1+ to L4+) |
| Maximum Lamp Load | 10 W |
| Rated Output Voltage | 24 V DC |
| Output Voltage for Signal "0" | Max. 2 V, idle |
| Output Voltage for Signal "1" | Min. UE - 3 V |
| Maximum Output Current for Signal "1" | 2 A, in groups of 4 |
| Residual Current for Signal "0" | Max. 1 mA |
| Switching Frequency – Resistive Load | Max. 100 Hz |
| Switching Frequency – Inductive Load | Max. 0.5 Hz |
| Switching Frequency – Lamp Load | Max. 8 Hz |
| Maximum Total Output Current per Group | 4 A, up to 60 °C |
| Maximum Unshielded Cable Length | 100 m |
| Communication Interface | PROFIBUS DP |
| Maximum PROFIBUS DP Transmission Rate | 12 Mbit/s |
| Bus Protocol | PROFIBUS DP |
| Bus Fault Indicator | BF, red LED |
| Digital Output Status Indicator | Green LED |
| Isolation Between Electronic Block and PROFIBUS DP | Yes |
| Channel Isolation | In groups of 4 |
| Operating Temperature – Horizontal Installation | 0 to 60 °C |
| Maximum Temperature – Other Mounting Positions | 40 °C |
| Permissible Air Pressure | 795–1080 hPa |
| Operating Relative Humidity | 15–95% |
| Humidity Class | RH Class 2 according to IEC 1131-2 |
| Vibration Resistance | IEC 60068-2-6; 10–57 Hz at 0.075 mm; 57–150 Hz at 1 g |
| Shock Resistance | IEC 60068-2-27; half-sine, 15 g, 11 ms |
| Electrical Connection | Screw-type and spring-loaded terminals, permanent wiring |
| Wiring | 3-wire and 4-wire connection |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7132-0BH11-0XB0 SIMATIC DP ET 200B Digital Electronic Module is a 16-channel digital output module designed for the SIMATIC ET 200B distributed I/O system. It provides 16 × 24 VDC outputs rated up to 2 A, with outputs isolated in groups of four and integrated electronic short-circuit protection for reliable control of industrial field devices. The module supports PROFIBUS DP communication at rates up to 12 Mbit/s, while LED indicators provide clear visualization of bus faults and individual output status. With support for resistive, inductive, and lamp loads, along with robust vibration and shock resistance, the 6ES7132-0BH11-0XB0 provides dependable output switching for distributed industrial automation and machine control systems.
The Siemens 6ES7132-0BH11-0XB0 is designed for controlling 24 VDC field devices such as solenoid valves, contactors, relays, indicator lamps, signaling devices, and other industrial actuators. Its 2 A output capacity and electronic short-circuit protection make it suitable for machinery, conveyor systems, packaging equipment, assembly lines, material handling systems, and automated production equipment requiring reliable switching of relatively high-current DC loads.
As part of the SIMATIC ET 200B platform, the module is also suitable for PROFIBUS DP-based distributed I/O architectures where output devices need to be located closer to machinery or production processes. It can be applied in factory automation, manufacturing plants, process equipment, logistics systems, and production lines, providing reliable PLC-to-field-device control while simplifying distributed wiring and system integration.
