Product Name: SIMATIC DP ET 200S 4 DO Standard 24V DC 2A Digital Output Electronic Module, 5-Pack
Brand Name: Siemens
Model Number: 6ES7132-4BD30-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Siemens 6ES7132-4BD30-0AA0 SIMATIC DP ET 200S 4 DO Standard 24V DC 2A Digital Output Electronic Module, 5-Pack |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200S 4 DO Standard 24V DC 2A Digital Output Electronic Module, 5-Pack |
| Part Number | 6ES7132-4BD30-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Module Configuration | 4 DO |
| Rated Output | 24 V DC / 2 A |
| Load Voltage L+ | 24 V DC, from power module |
| Reverse Polarity Protection | Yes |
| Current from Load Voltage L+ | 5 mA max. per channel, without load |
| Current from Backplane Bus | 10 mA max. at 3.3 V DC |
| Typical Power Loss | 1.6 W |
| Address Space with Packing | 2 bits |
| Address Space without Packing | 1 byte |
| Number of Digital Outputs | 4 |
| Short-Circuit Response Threshold | 2.8 to 7.2 A typ. |
| Inductive Shutdown Voltage Limitation | -55 to -60 V |
| Digital Input Control | Yes |
| Lamp Load Switching Capacity | 10 W max. |
| Load Resistance Range | 12 to 3,400 Ω |
| Output Voltage for Signal “1” | L+ (-1 V) min. |
| Rated Output Current | 2 A per output |
| Residual Current for Signal “0” | 0.5 mA max. |
| Output Delay “0” → “1” | 200 µs max. |
| Output Delay “1” → “0” | 1.3 ms max. |
| Parallel Switching for Increased Power | No |
| Parallel Switching for Redundant Load Control | Yes, per module |
| Switching Frequency – Resistive Load | 100 Hz max. |
| Switching Frequency – Inductive Load | 2 Hz max. (0.5 H) |
| Switching Frequency – Lamp Load | 10 Hz max. |
| Shielded Cable Length | 1,000 m max. |
| Unshielded Cable Length | 600 m max. |
| Isochronous Operation | No |
| Diagnostic Functions | No |
| Short-Circuit Diagnostic Message | Yes |
| Output Status Indicator | Green LED |
| Parameter / Remark | 1 byte |
| Isolation Between Output Channels | No |
| Isolation Between Outputs and Backplane Bus | Yes |
| Permissible Potential Difference | 75 V DC / 60 V AC |
| Isolation Test Voltage | 500 V DC |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7132-4BD30-0AA0 is a SIMATIC DP ET 200S Standard digital output electronic module supplied as a 5-pack for distributed automation applications. Each module provides 4 digital outputs rated for 24 V DC and up to 2 A per output, with support for resistive, inductive, and lamp loads. Fast output switching, short-circuit monitoring, status indication, and electrical isolation from the backplane bus support reliable operation and convenient system monitoring. Designed for controlling higher-current discrete field loads, the module is well suited for solenoid valves, relays, contactors, indicators, actuators, conveyor equipment, packaging machinery, and general factory automation.
1. What is the Siemens 6ES7132-4BD30-0AA0 used for?
The Siemens 6ES7132-4BD30-0AA0 is used to switch and control 24 V DC field loads in SIMATIC ET 200S distributed I/O systems, including solenoid valves, relays, contactors, indicators, and compatible actuators.
2. How many digital outputs does the Siemens 6ES7132-4BD30-0AA0 provide?
Each Siemens 6ES7132-4BD30-0AA0 module provides 4 digital output channels.
3. What is the rated output current of the Siemens 6ES7132-4BD30-0AA0?
Each output of the Siemens 6ES7132-4BD30-0AA0 is rated for up to 2 A.
4. What is the rated output voltage of the Siemens 6ES7132-4BD30-0AA0?
The Siemens 6ES7132-4BD30-0AA0 operates with a rated output and load voltage of 24 V DC.
5. Is the Siemens 6ES7132-4BD30-0AA0 supplied as a single module?
No. The Siemens 6ES7132-4BD30-0AA0 is specified as a 5-pack containing five digital output electronic modules.
6. Does the Siemens 6ES7132-4BD30-0AA0 support short-circuit diagnostics?
Yes. The Siemens 6ES7132-4BD30-0AA0 supports short-circuit diagnostic messaging to assist with fault detection.
7. Can the Siemens 6ES7132-4BD30-0AA0 control lamp loads?
Yes. The Siemens 6ES7132-4BD30-0AA0 supports compatible lamp loads up to 10 W.
