Siemens 6ES7132-4BF00-0AA0 Digital electronic module 8DO DC24V/0.5 A Original new

Siemens 6ES7132-4BF00-0AA0 Digital electronic module 8DO DC24V/0.5 A Original new

Product Name:Digital electronic module 8DO DC24V/0.5 A

Brand Name:Siemens

Model Number:6ES7132-4BF00-0AA0

Country of Origin:Germany

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7132-4BF00-0AA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	6ES7132-4BF00-0AA0
Type	Digital Output Module (DO)
Channels	8 Outputs
Rated Voltage	24 V DC
Output Current	0.5 A per channel
Total Current	4 A per module
Switching Frequency	Up to 100 Hz (resistive load)
Short-Circuit Protection	Yes (electronic)
Response Time	0.3–0.6 ms
Electrical Isolation	Yes (backplane separated)
Cable Length	600 m (unshielded), 1000 m (shielded)
Dimension (W×H×D)	15 × 81 × 52 mm
Weight	approx. 40 g
Mounting System	ET200S terminal modules
Operating Mode	Isochronous supported

Description

The Siemens SIMATIC ET200S digital output module 6ES7132-4BF00-0AA0 is a compact 8-channel DO solution designed for reliable 24 V DC switching in distributed automation systems. As part of the SIMATIC S7-300 / ET200S family, it provides precise control of actuators such as solenoid valves, DC contactors, and signal lamps, ensuring stable performance in industrial environments.

The main model 6ES7132-4BF00-0AA0 features 8 isolated digital outputs with 0.5 A per channel and integrated short-circuit protection. It supports isochronous operation and delivers fast switching response suitable for time-critical control tasks in modern PLC architectures.

Variants within the Siemens 6ES7132 series maintain high compatibility with ET200S interface modules, offering flexible integration for scalable automation systems in process and manufacturing industries.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Support process automation and intrinsically safe output switching.
Steel mills: Provide robust control in high-temperature and EMI-heavy environments.
Machinery manufacturing: Applied in automated production lines, robots, and packaging systems.

Features

8-channel compact digital output design
24 V DC industrial switching capability
Short-circuit and overload protection per channel
Fast response for real-time PLC control
Modular ET200S system integration
High noise immunity for harsh environments

Functions

Controls actuators such as valves and relays
Executes fast ON/OFF switching signals
Supports distributed I/O automation architecture
Provides isolated signal transmission to PLC systems
Ensures stable output under industrial load conditions

FAQ

Q1: What is the main use of 6ES7132-4BF00-0AA0?
A1: It is used for controlling industrial actuators like valves, relays, and indicators in PLC systems.

Q2: How many outputs does the module provide?
A2: It provides 8 digital outputs with independent channels.

Q3: What is the output rating per channel?
A3: Each channel supports up to 0.5 A at 24 V DC.

Q4: Is the module protected against short circuits?
A4: Yes, each output channel has built-in electronic short-circuit protection.

Q5: Can it be used in harsh industrial environments?
A5: Yes, it is designed for stable operation in high EMI and industrial conditions.
