Product Name: ET 200SP. DQ 16x 24V DC/0.5A ST. PU 1 Digital Input Module
Brand Name: SIEMENS
Model Number: 6ES7132-6BH01-0BA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7132-6BH01-0BA0 ET 200SP. DQ 16x 24V DC/0.5A ST. PU 1 Digital Input Module |
| Manufacturer | SIEMENS |
| Product Type | ET 200SP. DQ 16x 24V DC/0.5A ST. PU 1 Digital Input Module |
| Part Number | 6ES7132-6BH01-0BA0 |
| Weight | 0.5kg |
| Estimated shipping dimensions | 23x19.2x3.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Reverse polarity protection | Yes |
| Current consumption, max. | 60 mA; without load |
| Rated value (DC) | 24 V |
| Power loss, typ. | 1 W |
| Address space per module, max. | 2 byte; + 2 bytes for QI information |
| Automatic encoding | Yes |
| lower limit | 48 Ω |
| upper limit | 12 kΩ |
| with resistive load, max. | 0.5 A |
| on lamp load, max. | 5 W |
| with resistive load, max. | 100 Hz |
| with inductive load, max. | 2 Hz |
| on lamp load, max. | 10 Hz |
| Siemens PLC Output Module | PLC Digital Output Interface |
| Distributed I/O Module | Industrial Signal Output Module |
| Digital Output Card | Siemens Control System Hardware |
| ET200SP Automation Module | Distributed Automation Module |
| Industrial Control Output Module | Machine Control Output Module |
| Siemens I/O Module | High Density Output Module |
| Factory Automation Output Card | Industrial Actuator Control Module |
| PLC Field Output Module | Siemens Automation Hardware |
| Industrial Electronics Module | ET200SP Expansion Module |
The Siemens 6ES7132-6BH01-0BA0 is a digital output module designed for the SIMATIC ET 200SP distributed I/O platform. It provides 16 output channels for controlling industrial actuators, relays, solenoids, indicator lamps, and other field devices requiring 24 VDC switching signals.
Featuring a compact design, automatic module encoding, and low power consumption, the 6ES7132-6BH01-0BA0 delivers reliable performance in modern automation systems. It is ideal for machine control, manufacturing equipment, and distributed industrial applications requiring efficient digital output management.
Digital Output Control
Provides 16 output channels for switching and controlling industrial field devices.
24 VDC Signal Switching
Delivers reliable 24 VDC output signals for automation and control applications.
Actuator Operation
Controls relays, solenoids, contactors, indicators, and other output devices.
Automatic Module Recognition
Features automatic encoding to simplify installation and reduce configuration errors.
Load Management
Supports resistive, inductive, and lamp loads for versatile industrial applications.
Distributed I/O Integration
Operates seamlessly within Siemens ET 200SP distributed automation systems.
Output Status Transmission
Uses dedicated address space for output data and quality information exchange.
Reverse Polarity Protection
Provides protection against incorrect power wiring to improve system safety.
Compared with similar digital output modules, the Siemens 6ES7132-6BH01-0BA0 offers high channel density, automatic module identification, and reliable load handling, making it an efficient solution for distributed automation systems.
16-Channel Compact Design: Delivers high output density while minimizing cabinet space requirements.
Automatic Encoding Feature: Simplifies commissioning and reduces installation errors.
Low Power Consumption: Requires minimal operating power while maintaining reliable performance.
Flexible Load Compatibility: Supports resistive, inductive, and lamp loads in industrial applications.
Built-In Reverse Polarity Protection: Enhances system safety and protects against wiring mistakes.
Seamless ET 200SP Integration: Designed specifically for Siemens distributed I/O architectures.
Reliable Industrial Performance: Provides stable operation in demanding automation environments.
What is 6ES7132-6BH01-0BA0 used for?
The 6ES7132-6BH01-0BA0 is used to control industrial actuators and field devices within ET 200SP distributed I/O systems.
How many output channels does 6ES7132-6BH01-0BA0 provide?
The 6ES7132-6BH01-0BA0 provides 16 digital output channels.
What voltage does 6ES7132-6BH01-0BA0 operate with?
The 6ES7132-6BH01-0BA0 operates with a rated voltage of 24 VDC.
What is the maximum output current of 6ES7132-6BH01-0BA0?
The 6ES7132-6BH01-0BA0 supports up to 0.5 A per output channel with resistive loads.
Does 6ES7132-6BH01-0BA0 provide reverse polarity protection?
Yes, the 6ES7132-6BH01-0BA0 includes built-in reverse polarity protection.
Can 6ES7132-6BH01-0BA0 control lamp loads?
Yes, the 6ES7132-6BH01-0BA0 supports lamp loads up to 5 W.
Which automation platform is 6ES7132-6BH01-0BA0 designed for?
The 6ES7132-6BH01-0BA0 is designed for the SIMATIC ET 200SP distributed I/O platform.
