Siemens 6ES7134-0HF01-0XB0 SIMATIC DP ET 200B 4AI Analog Electronic Module

Siemens 6ES7134-0HF01-0XB0 SIMATIC DP ET 200B 4AI Analog Electronic Module

Product Name: SIMATIC DP ET 200B 4AI Analog Electronic Module

Brand Name: Siemens

Model Number: 6ES7134-0HF01-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7134 0hf01 0xb0 simatic dp et 200b 4ai analog electronic module-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The Siemens 6ES7134-0HF01-0XB0 SIMATIC DP ET 200B 4AI Analog Electronic Module is an analog input module designed for the SIMATIC DP ET 200B distributed I/O system. It provides four high-performance analog input channels supporting voltage and current measurement ranges, including 0–20 mA and ±1.25 V to ±10 V. Featuring 12-bit resolution, fast 5 ms total conversion time, and PROFIBUS DP communication at up to 12 Mbit/s, the module delivers accurate and reliable analog signal acquisition for industrial process monitoring and automation applications.

Product Parameters

Product Name	Siemens 6ES7134-0HF01-0XB0 SIMATIC DP ET 200B 4AI Analog Electronic Module
Manufacturer	Siemens
Product Type	SIMATIC DP ET 200B 4AI Analog Electronic Module
Part Number	6ES7134-0HF01-0XB0
Place of shipment	Xiamen, China
Country of origin	Germany
Analog Inputs	4
Input Ranges	0–20 mA, ±1.25 V, ±2.5 V, ±5 V, ±10 V
Resolution	12-bit (Two's Complement)
Conversion Type	Fast Conversion
Maximum Conversion Time	5 ms (All Channels)
Integration Time	0.1 ms per Channel
Required Terminal Block	TB8
Rated Supply Voltage	24 V DC
Supply Voltage Range	18.5 to 30.2 V DC
Logic Current Consumption	Typical 70 mA
Typical Power Dissipation	1.8 W
Maximum Voltage Input	±30 V Continuous, ±75 V Pulse (1 ms Max.)
Maximum Current Input	24 mA
Voltage Input Resistance	100 kΩ
Current Input Resistance	125 Ω
Maximum Cable Length	100 m (Shielded)
Supported Transducers	Voltage, 2-Wire Current, 4-Wire Current
Basic Accuracy (25 °C)	±0.15% (Voltage), ±0.20% (Current)
Common-Mode Noise Rejection	≥70 dB
Maximum Common-Mode Voltage	±10 V Between Inputs, ±1 V Between Inputs and MANA
Communication Protocol	PROFIBUS DP
Maximum Transmission Rate	12 Mbit/s
Protection Rating	IP20
Operating Temperature	0 to +60 °C (Horizontal Installation)
Relative Humidity	15–95% RH
Connection Method	Screw-Type or Spring-Loaded Terminals (3- or 4-Wire)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

Four Analog Input Channels
Provides four analog inputs for accurate acquisition of voltage and current signals.
Multiple Input Signal Ranges
Supports 0–20 mA, ±1.25 V, ±2.5 V, ±5 V, and ±10 V input ranges for application flexibility.
High Measurement Accuracy
Offers 12-bit resolution with basic accuracy of ±0.15% for voltage inputs and ±0.20% for current inputs.
Fast Signal Conversion
Completes conversion of all four channels within 5 ms with an integration time of only 0.1 ms per channel.
PROFIBUS DP Communication
Supports PROFIBUS DP communication with transmission rates up to 12 Mbit/s for seamless distributed automation.
Wide Sensor Compatibility
Supports voltage transducers as well as 2-wire and 4-wire current transmitters.
Excellent Noise Immunity
Provides common-mode noise rejection of at least 70 dB for stable and reliable signal measurement.
Industrial-Grade Design
Features IP20 protection, flexible screw or spring-loaded terminal connections, and operation from 0°C to +60°C.

FAQ

---What is the 6ES7134-0HF01-0XB0 used for?
6ES7134-0HF01-0XB0 is used to acquire analog voltage and current signals in SIMATIC DP ET 200B distributed I/O systems.

---How many analog input channels does the 6ES7134-0HF01-0XB0 provide?
6ES7134-0HF01-0XB0 provides four analog input channels.

---Which types of transducers are compatible with the 6ES7134-0HF01-0XB0?
6ES7134-0HF01-0XB0 supports voltage transducers as well as 2-wire and 4-wire current transmitters.

---What communication protocol does the 6ES7134-0HF01-0XB0 support?
6ES7134-0HF01-0XB0 supports PROFIBUS DP communication with transmission rates of up to 12 Mbit/s.

---What terminal block is required for the 6ES7134-0HF01-0XB0?
6ES7134-0HF01-0XB0 requires the TB8 terminal block for installation.

---What are the main benefits of the 6ES7134-0HF01-0XB0?
6ES7134-0HF01-0XB0 provides accurate analog signal acquisition, fast conversion, multiple input range support, excellent noise immunity, reliable PROFIBUS DP communication, and dependable performance for distributed industrial automation systems.
