Product Name: SIMATIC ET 200S 2 AI TC High Feature Analog Input Module
Brand Name: Siemens
Model Number: 6ES7134-4NB00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
| Sales | Phone/Whatsapp | |
| Jim Pei | [email protected] | +86 18020776782 |
| Official article number | 6ES7134-4NB00-0AB0 |
| Manufacturer | Siemens AG |
| Product family | SIMATIC ET 200S |
| Rated value (DC) | 24 V; From power module |
| Reverse polarity protection | Yes |
| from load voltage L+ (without load), max. | 30 mA |
| from backplane bus 3.3 V DC, max. | 10 mA |
| Power loss, typ. | 0.6 W |
| Address space per module, max. | 4 byte |
| Number of analog inputs | 2 |
| permissible input voltage for voltage input | 20 V; ±20 V, continuous |
| Cycle time (all channels) max. | Number of active channels per module x basic conversion time |
| Technical unit for temperature measurement | Yes; Celsius / Fahrenheit |
| -80 mV to +80 mV | Yes |
| Input resistance (-80 mV to +80 mV) | 1 MΩ |
| Type B | Yes |
| Input resistance (Type B) | 1 MΩ |
| Type C | Yes |
| Input resistance (Type C) | 1 MΩ |
| Type E | Yes |
| Input resistance (Type E) | 1 MΩ |
| Type J | Yes |
| Input resistance (type J) | 1 MΩ |
| Type K | Yes |
| Input resistance (Type K) | 1 MΩ |
| 6ES7134-4NB00-0AB0 | Subject to change without notice |
| Type L | Yes |
| Input resistance (Type L) | 1 MΩ |
| Type N | Yes |
| Input resistance (Type N) | 1 MΩ |
| Type R | Yes |
| Input resistance (Type R) | 1 MΩ |
| Type S | Yes |
| Input resistance (Type S) | 1 MΩ |
| Type T | Yes |
| Input resistance (Type T) | 1 MΩ |
| internal temperature compensation | Yes; possible with TM-E15S24-AT, TM-E15C24-AT |
| external temperature compensation with | Yes; one external compensating box per channel |
| parameterizable | Yes |
| for thermocouples | Type B, C, E, J, K, L, N, R, S, T to IEC 584 |
| shielded, max. | 50 m |
| Measurement principle | integrating |
| Resolution with overrange (bit including sign), | 16 bit; 15 bit + sign |
| Integration time, parameterizable | Yes |
| Integration time (ms) | 16,7 / 20 ms |
| Interference voltage suppression for | 50 / 60 Hz |
| Conversion time (per channel) | 66 ms; 66 / 80 ms; additional conversion time for diagnostic wire |
| parameterizable | Yes; In four stages by means of digital filtering |
| Step: None | Yes; 1x cycle time |
| Step: low | Yes; 4x cycle time |
| Step: Medium | Yes; 32x cycle time |
| Step: High | Yes; 64x cycle time |
| for voltage measurement | Yes |
| Linearity error (relative to input range), (+/-) | 0.01 % |
| Temperature error (relative to input range), (+/-) | 0.005 %/K |
| Crosstalk between the inputs, min. | -50 dB |
| Repeat accuracy in steady state at 25 °C (relative to | 0.05 % |
| Voltage, relative to input range, (+/-) | 0.1 %; ±1.5 K for thermocouples, ±7 K for thermocouples type C, |
| Voltage, relative to input range, (+/-) | 0.05 %; ±1 K with thermocouples, ±5 K with thermocouples type |
| Series mode interference (peak value of | 70 dB |
| Common mode interference (USS < 2.5 V) , | 90 dB |
| Isochronous operation (application synchronized up | No |
| Wire-break | Yes |
| Group error | Yes |
| Overflow/underflow | Yes |
| Group error SF (red) | Yes |
| Remark | 4 byte |
| Diagnostics wire break | Disable / enable |
| Measurement type/range | Deactivated/ ±80 mV/ TC-EL Type T (Cu-CuNi)/ TC-EL Type K |
| Group diagnostics | Disable / enable |
| Overflow/underflow | Disable / enable |
| Comparison point | none / yes, internal |
| between the channels | No |
| between the channels and backplane bus | Yes |
| Between the channels and load voltage L+ | Yes |
| Between the inputs and MANA (UCM) | 140 V DC/100 V AC |
| between MANA and M internally (UISO) | 75 V DC/60 V AC |
| Isolation tested with | 500 V DC |
6ES7134-4NB00-0AB0 is a Siemens SIMATIC ET 200S 2 AI TC High Feature Analog Input Module with two thermocouple inputs. Its official product data identifies 15-bit plus sign resolution and internal temperature compensation. This Siemens SIMATIC ET 200S product is engineered for dependable integration into compatible industrial automation systems. It supports clear product identification for engineering, replacement, and maintenance workflows. The genuine Siemens article helps maintain consistent system architecture and organized spare-parts planning. For sourcing and lifecycle support, 6ES7134-4NB00-0AB0 is a precisely identified Siemens industrial automation solution.
