Product Name: Analog Current Input Module
Brand Name: Siemens
Model Number: 6ES7134-5RB00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7134-5RB00-0AB0 Analog Current Input Module |
| Manufacturer | Siemens |
| Product Type | Analog Current Input Module |
| Part Number | 6ES7134-5RB00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Inputs | 2 |
| Input Type | Current Input |
| Input Range | 4 to 20 mA |
| Maximum Permitted Input Current | 90 mA (Destruction Limit) |
| Supported Transducer | 2-Wire Transducer |
| Transducer Supply | Yes |
| Maximum Supply Current | 23 mA per Channel |
| Maximum Load Impedance | 750 Ω |
| Maximum Shielded Cable Length | 200 m |
| Protection Rating | CENELEC II2(1)G EEx ib[ia] IIC T4 CE0344 |
| FM Certification | Class I, Division 2, Groups A, B, C, D; Class I, Zone 2; Class I, Zone 1 |
| Isolation Test Voltage | 500 VAC |
| Current Consumption | 280 mA Max from Load Voltage (Power Bus) |
| Typical Power Loss | 3.36 W |
| Measurement Principle | Integrating (Sigma-Delta) |
| Interference Frequency Suppression | 50 Hz / 60 Hz |
| Basic Conversion Time | 30 ms per Channel |
| Cycle Time | Number of Active Channels × 30 ms |
| Resolution | 12 Bits + Sign |
| Measurement Value Smoothing | None (1× Cycle Time), Weak (4×), Medium (32×), Strong (64×) |
| Normal-Mode Interference Rejection | ≥70 dB |
| Crosstalk Between Inputs | ≥50 dB |
| Operational Error Limit | ±0.15% of Input Range |
| Basic Error Limit (25°C) | ±0.1% of Input Range |
| Temperature Error | ±0.03% of Input Range |
| Linearity Error | ±0.0015% of Input Range |
| Repeatability | ±0.01% of Input Range at 25°C |
| Limit Value Interrupt | Yes, Selectable |
| Diagnostic Interrupt | Yes, Selectable |
| Group Error Indicator | Red SF LED |
| Diagnostic Information | Readable |
| Short-Circuit Monitoring | I < 23.8 mA |
| Wire-Break Monitoring | I < 3.6 mA |
| EU Prototype Test Certificate | KEMA 01 ATEX 1152 X |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7134-5RB00-0AB0 Analog Current Input Module is a high-precision 2-channel analog current input module designed for reliable signal acquisition in SIMATIC distributed I/O systems. It features two 4–20 mA current inputs, integrated transducer power supply, Sigma-Delta conversion technology, 12-bit resolution, and selectable diagnostic and limit value interrupts for accurate process monitoring. The module delivers stable measurement performance with excellent noise immunity and supports comprehensive diagnostics for improved system reliability. Its seamless integration with Siemens automation platforms makes it an ideal solution for process automation, chemical processing, oil and gas, water treatment, power generation, and manufacturing applications.
The Siemens 6ES7134-5RB00-0AB0 Analog Current Input Module is designed for acquiring 4–20 mA analog signals from transmitters, sensors, and other field instruments in industrial automation systems. It is widely used for monitoring process variables such as pressure, temperature, flow, and level in PLC and distributed I/O applications where accurate current signal measurement and reliable diagnostics are essential.
With intrinsic safety certification and support for hazardous-area installations, the module is well suited for process industries including oil and gas, chemical processing, power generation, water treatment, and pharmaceutical manufacturing. Its high measurement accuracy, integrated transmitter supply, and advanced diagnostic capabilities help improve process reliability, simplify maintenance, and ensure stable operation in demanding industrial environments.
