Siemens 6ES7134-6GD01-0BA1 high-precision SIMATIC ET 200SP analog input module In stock

Siemens 6ES7134-6GD01-0BA1 high-precision SIMATIC ET 200SP analog input module In stock

Product Name:SIMATIC ET 200SP analog input module

Brand Name:Siemens

Model Number:6ES7134-6GD01-0BA1

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7134 6gd01 0ba1 high precision simatic et 200sp analog input module in stock-1

Overview
Get your discount today
Specifications
Description
Applications
Technical Data Summary
Environment and certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7134-6GD01-0BA1
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Get your discount today

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 1815988 9985

Specifications

Parameter	Specification
Product Model	6ES7134-6GD01-0BA1
Product Type	SIMATIC ET 200SP AI 4xI 2-/4-wire ST
Input Channels	4 differential analog inputs
Signal Type	Current measurement (0–20 mA / 4–20 mA / ±20 mA)
Resolution	Up to 16-bit (incl. sign)
Input Resistance	100 Ω
Supply Voltage	24 V DC (19.2–28.8 V DC)
Power Loss	Typ. 0.85 W
Encoder Supply	24 V DC, max 20 mA per channel
Cable Length	Up to 1000 m (shielded)
Diagnostics	Wire break, short circuit, overload, supply monitoring
Communication System	PROFINET / PROFIBUS via ET 200SP
Mounting Type	ET 200SP BaseUnit A0 / A1
Operating Temperature	-30°C to +60°C
Protection Isolation	707 V DC tested
Dimensions	15 × 73 × 58 mm (W × H × D)
Weight	Approx. 31 g

Description

Siemens 6ES7134-6GD01-0BA1 is a high-precision SIMATIC ET 200SP analog input module (AI 4xI 2-/4-wire ST) designed for accurate current signal acquisition in distributed automation systems. Supporting 4 differential analog inputs with 16-bit resolution, it ensures stable measurement performance with high signal integrity and integrated diagnostics for industrial applications.

Compatible with ET 200SP BaseUnits A0 and A1 and other Siemens 6ES7134 series modules, the 6ES7134-6GD01-0BA1 enables flexible integration into modern PLC architectures via PROFINET or PROFIBUS systems. Its compact design, fast response time, and robust signal processing make it ideal for demanding control environments.

Engineered for industrial automation, this module delivers reliable analog signal processing, high accuracy, and seamless system scalability for continuous process monitoring and control.
