Product Name:3300 XL 8 mm Proximity Probes
Brand Name:Bently Nevada
Model Number:330103-00-06-10-02-CN
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-00-06-10-02-CN |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Description |
|
Model |
330103-00-06-10-02-CN |
|
Type |
8 mm Proximity Probe |
|
Thread |
M10 x 1 |
|
Armor |
None |
|
Total Length |
1.0 m system compatible |
|
Connector Type |
Miniature coaxial ClickLoc |
|
Cable Type |
Standard triaxial cable |
|
Output Signal |
Eddy current analog voltage |
|
Operating Temp |
-52°C to +177°C |
|
Weight |
0.08kg |
|
Material |
Stainless steel probe case |
|
Dimension |
1.8x1.5x123cm |
330103-00-06-10-02-CN is a high-precision eddy current sensing solution designed for reliable vibration and position monitoring in industrial machinery. It is part of the 3300 XL 8 mm transducer system, widely used for accurate shaft displacement measurement in rotating equipment such as turbines, compressors, and pumps.
This probe features an M10 x 1 threaded design without armor, ensuring flexible installation in standard mounting configurations. It supports ClickLoc connectors and is engineered for stable signal transmission, strong mechanical durability, and excellent resistance to electromagnetic interference. The modular structure allows seamless compatibility with extension cables and Proximitor sensors within the 3300 XL series.
Widely deployed in condition monitoring systems, the 330103 probe delivers consistent performance in harsh industrial environments. It is suitable for critical applications requiring continuous vibration data acquisition, helping improve machine reliability, reduce downtime, and enhance predictive maintenance strategies.
Q1: What is 330103-00-06-10-02-CN used for?
A1: It is used for measuring vibration and shaft displacement in industrial rotating machinery.
Q2: Is the 330103 probe compatible with 3300 XL systems?
A2: Yes, it is fully compatible with 3300 XL extension cables and Proximitor sensors.
Q3: Does this probe include armor protection?
A3: No, this model is designed without armor for standard installation environments.
Q4: What industries commonly use this probe?
A4: It is widely used in power plants, chemical plants, steel mills, and manufacturing industries.
Q5: What type of connector does it use?
A5: It uses a miniature coaxial ClickLoc connector for secure and reliable connections.
| Number | Description |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing (12”x12”x6”), supports up to 8 Proximitor Sensors (DIN mount) or 6 sensors (panel mount), ATEX Zone 0/1 certified |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing (12”x8”x6”), supports up to 4 Proximitor Sensors in DIN or panel mount configuration, ATEX Zone 0/1 certified |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing (13”x9.5”x7”), supports up to 8 sensors (DIN) or 6 sensors (panel), suitable for hazardous area installations, ATEX and North American Division certified |
| 02120015 | Bulk field wire, 1.0 mm² (18 AWG), 3-conductor twisted shielded cable with drain wire, available in custom length |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL installation systems |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL installation systems |
| 148722-01 | 3300 XL test plug with 3 test pins, color-coded 1-meter wires and banana plugs for sensor performance testing without removing field wiring |
| 04310310 | Proximitor sensor panel-mount screw (6-32 UNC), 4 screws required per sensor, standard mounting hardware |
| 03200006 | Silicone self-fusing tape (9.1 m roll), provides electrical insulation and environmental protection for connectors |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes installation tools and accessories |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors |
| 40180-02 | Package of connector protectors (10 pairs) for 3300 XL probes and extension cables |
| 03839410 | 75Ω triaxial male connector protector for environmental sealing of probe-to-cable connections |
| 03839420 | 75Ω triaxial female connector protector for probe leads and extension cable protection |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mechanical fixation |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure probe installation |
