Siemens 6ES7134-6HB00-0CA1 Analog Input Module

Siemens 6ES7134-6HB00-0CA1 Analog Input Module

Product Name: Analog Input Module

Brand Name: Siemens

Model Number: 6ES7134-6HB00-0CA1

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7134 6hb00 0ca1 analog input module -1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7134-6HB00-0CA1 is an analog input module designed for industrial automation systems. Identified as the AI 2xU/I 2-/4-wire HF module, it is used for precise acquisition and processing of analog voltage and current signals from field devices and sensors.

This module supports both 2-wire and 4-wire sensor connections, providing flexible integration for various industrial measurement and monitoring applications. Its high-feature (HF) design ensures reliable analog signal conversion and stable performance in demanding automation environments.

With compact dimensions and efficient power consumption, the 6ES7134-6HB00-0CA1 is suitable for distributed automation systems requiring accurate analog data collection and dependable long-term operation.

Functions

Converts analog voltage and current signals into digital data for PLC and automation system processing
Collects measurement data from industrial sensors and transmitters
Supports both 2-wire and 4-wire analog device connections
Enables real-time monitoring and control of industrial process variables
Provides stable sensor power supply for connected field instruments
Ensures reliable analog signal transmission in distributed automation systems
Protects input channels through integrated reverse polarity and short-circuit protection
Supports accurate data acquisition for process automation, instrumentation, and monitoring applications

Features

2-Channel Analog Input Module
Supports analog voltage and current signal acquisition for industrial applications.
2-Wire and 4-Wire Sensor Support
Compatible with a wide range of industrial transmitters and analog sensors.
24V DC Industrial Operation
Operates within a 19.2–28.8V DC supply range.
Reverse Polarity Protection
Integrated protection helps prevent damage from incorrect wiring connections.
Integrated Short-Circuit Protection
Channel-by-channel protection enhances operational reliability and safety.
Efficient Current Supply Capability
- Up to 50 mA per channel (<10 s) for 2-wire sensors
- Up to 150 mA (<10 s) for 4-wire sensors
Low Power Consumption
Typical power loss of approximately 0.95 W without sensor supply.
Compact Module Design
Small form factor suitable for space-limited industrial control systems.
High Reliability Signal Processing
Designed for stable and accurate analog data acquisition in industrial environments.
Industrial-Grade Construction
Built for continuous operation in demanding automation applications.

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7134-6HB00-0CA1 Analog Input Module
Manufacturer	Siemens
Product Type	Analog Input Module
Part Number	6ES7134-6HB00-0CA1
Estimated shipping dimensions	1.4x5.7x7.2cm
Weight	0.04kg
Place of shipment	Xiamen, China
Country of origin	Germany
Product type designation	AI 2xU/I 2-/4-wire HF
Rated value (DC)	24 V
permissible range, lower limit (DC)	19.2 V
permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Current consumption (rated value)	39 mA; without sensor supply
Output current, max.	20 mA; max. 50 mA per channel for a duration < 10 s (two-wire)
Short-circuit protection	Yes; channel by channel
Output current, max.	100 mA; max. 150 mA for a duration of < 10 s (four-wire)
Power loss, typ.	0.95 W; without sensor supply

Application Scenarios

Industrial process monitoring systems
Pressure, temperature, and flow sensor integration
Analog measurement and data acquisition applications
Factory automation and process control systems
Distributed I/O automation architectures
Industrial instrumentation and monitoring equipment

Operating Environment

The Siemens 6ES7134-6HB00-0CA1 analog input module is designed for installation in industrial automation systems and control cabinets. It operates using a standard 24V DC industrial power supply and supports integration with distributed I/O and control architectures.

The module is intended for continuous operation in industrial environments where stable analog signal acquisition is required. Its robust design allows reliable performance in environments exposed to electrical interference, vibration, and demanding operating conditions commonly found in manufacturing and process industries.

Its compact structure and integrated protection features make it suitable for modern automation systems requiring accurate sensor data collection and long-term operational stability.
