Siemens 6ES7134-7SD00-0AB0 ELECT. SUBMODULE FOR ET200ISP Ready For Ship

Siemens 6ES7134-7SD00-0AB0 ELECT. SUBMODULE FOR ET200ISP Ready For Ship

Product Name:ELECT. SUBMODULE FOR ET200ISP

Brand Name:Siemens

Model Number:6ES7134-7SD00-0AB0

Country of Origin:Germany

Warranty: 12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7134 7sd00 0ab0 elect submodule for et200isp ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7134-7SD00-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Description
Product Model	6ES7134-7SD00-0AB0
Product Type	ET 200iSP Thermocouple Input Module
Channels	4 AI (TC)
Input Type	Thermocouple / Voltage
Voltage Range	-80 mV to +80 mV
Resolution	16-bit
Cycle Time	66–320 ms (depending on filtering)
Input Resistance	1000 kΩ
Power Loss	0.4 W (typ.)
Supply Current	max. 30 mA
Cable Length	up to 50 m (shielded)
Width	30 mm
Height	129 mm
Depth	136.5 mm
Weight	approx. 230 g

Description

The 6ES7134-7SD00-0AB0 is a Siemens SIMATIC DP electronic submodule designed for ET 200iSP systems, providing four thermocouple (TC) analog input channels for precise temperature measurement. It supports multiple thermocouple types, making it suitable for flexible industrial temperature monitoring applications in distributed automation environments.

The 6ES7134-7SD00-0AB0 delivers high-accuracy signal acquisition using sigma-delta conversion technology with 16-bit resolution. It ensures stable performance even in electrically noisy environments through strong interference suppression and integrated signal smoothing functions. Internal and external compensation options further improve measurement reliability.

As part of the ET 200iSP safety-oriented I/O family, the 6ES7134-7SD00-0AB0 is widely used in process industries requiring accurate thermal monitoring. Its compact modular design, diagnostic capabilities, and explosion-protection suitability make it ideal for demanding automation systems in harsh industrial conditions.

Applications

Power plants: Generator temperature monitoring and protection systems
Substations: Thermal supervision of switchgear and busbar systems
Chemical plants: Process temperature control and safety monitoring
Steel mills: High-temperature furnace and equipment monitoring
Machinery manufacturing: Automated production temperature feedback control

Features

4-channel thermocouple (TC) input support
High-resolution 16-bit signal conversion
Multi-type thermocouple compatibility (J, K, T, S, etc.)
Strong interference suppression (50/60 Hz)
Integrated diagnostic alarm and LED status indication
Compact ET 200iSP modular design
Suitable for hazardous area applications (ATEX certified)

Functions

Temperature signal acquisition and conversion
Thermocouple linearization and compensation
Real-time diagnostic monitoring
Signal filtering and smoothing adjustment
Fault detection and alarm reporting
Integration into distributed ET 200 systems

FAQ

Q1: What is the main function of 6ES7134-7SD00-0AB0?
A1: It measures temperature signals using 4 thermocouple input channels in ET 200iSP systems.

Q2: Which thermocouple types are supported?
A2: It supports multiple types including J, K, T, S, N, E, and more.

Q3: What is the resolution of this module?
A3: The module provides up to 16-bit resolution for accurate temperature measurement.

Q4: Is it suitable for hazardous environments?
A4: Yes, it is certified for ATEX hazardous area applications.

Q5: Can it suppress electrical interference?
A5: Yes, it includes strong 50/60 Hz interference suppression and signal filtering functions.
