Product Name: 8mm Eddy Current Sensor
Brand Name: Emerson
Model Number: PR6423/10R-040 CON021
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Emerson PR6423 Sensor | Rotating Machinery Protection |
| Non-contact Displacement Sensor | Predictive Maintenance Sensor |
| Shaft Vibration Sensor | High-Precision Position Sensor |
| Eddy Current Probe | Shaft Position Monitoring |
| Turbomachinery Monitoring | Industrial Automation Sensor |
| Dynamic Displacement Measurement | Radial Shaft Displacement Sensor |
| Industrial Vibration Monitoring | Ferromagnetic Steel Monitoring |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | Emerson PR6423/10R-040 CON021 8mm Eddy Current Sensor |
| Manufacturer | Emerson |
| Product Type | 8mm Eddy Current Sensor |
| Part Number | PR6423/10R-040 CON021 |
| Weight | 0.45 kg |
| Estimated shipping dimensions | 28x24x4cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Deviation from best fit straight line(DSL) | ± 0.025 mm (± 1 mil)@ temperature range 0 to 45°C (+32 to +113°F) |
| Linear Measurement Range | 2 mm (80 mils) |
| Initial Air Gap | 0.5 mm (20 mils) |
| Minimum Shaft Diameter | 25 mm (0.79”) |
| Target Material (Ferromagnetic Steel) | 42CrMo4 (AISI/SAE 4140) Standard |
The Emerson PR6423/10R-040 CON021 8mm Eddy Current Sensor is a high-precision non-contact displacement sensor designed for vibration and position monitoring in rotating machinery applications. It is widely used in turbines, compressors, pumps, and other critical industrial equipment requiring accurate shaft displacement measurement and continuous condition monitoring.
The sensor provides a linear measurement range of 2 mm (80 mils) with excellent accuracy and stability. Its deviation from the best fit straight line (DSL) is ±0.025 mm (±1 mil) within the temperature range of 0 to 45°C, ensuring reliable and precise measurement performance. The sensor operates with an initial air gap of 0.5 mm and supports shaft diameters starting from 25 mm.
Designed for industrial environments, the Emerson PR6423/10R-040 CON021 is optimized for ferromagnetic steel targets such as 42CrMo4 (AISI/SAE 4140) materials commonly used in rotating shafts. Its robust construction and stable non-contact sensing technology make it suitable for predictive maintenance and machinery protection systems.
Mechanical Configuration
The sensor features a compact 8 mm probe design suitable for installation in industrial rotating machinery systems. It supports shaft diameters of 25 mm or larger and operates with a 0.5 mm initial air gap for stable non-contact measurement.
Electrical Configuration
The sensor provides a 2 mm linear measurement range with high accuracy and a deviation from best fit straight line of ±0.025 mm. It delivers stable displacement signals for precise vibration and position monitoring.
Environmental Configuration
The sensor maintains accurate measurement performance within the temperature range of 0 to 45°C and is designed for continuous operation in industrial monitoring environments.
System Integration Configuration
The PR6423/10R-040 CON021 integrates with eddy current monitoring systems, vibration monitoring modules, and machinery protection systems for real-time shaft condition monitoring.
Programming & Monitoring Functions
The sensor supports predictive maintenance and rotating equipment protection by providing accurate real-time displacement and vibration data for detecting imbalance, misalignment, and shaft instability.
