Product Name: Analog Input Module
Brand Name: Siemens
Model Number: 6ES7134-7TD00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7134-7TD00-0AB0 Analog Input Module |
| Manufacturer | Siemens |
| Product Type | Analog Input Module |
| Part Number | 6ES7134-7TD00-0AB0 |
| Weight | 0.28kg |
| Estimated shipping dimensions | 3x13.4x12.8cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| from supply voltage L+, max. | 320 mA |
| short-circuit proof | Yes |
| Supply current, max. | 23 mA; per channel |
| Power loss, typ. | 2.7 W |
| Number of analog inputs | 4 |
| Cycle time (all channels) max. | 120 ms; 30 ms basic conversion time x 4 channels with 60 Hz, 50 Hz interference frequency suppression |
| shielded, max. | 500 m |
| Measurement principle | integrating (Sigma-Delta) |
| Resolution with overrange (bit including sign),max. | 13 bit |
| Burden of 2-wire transmitter, max. | 750 Ω |
| Temperature error (relative to input range), (+/-) | 0.005 %/K |
| Crosstalk between the inputs, min. | -50 dB |
The Siemens 6ES7134-7TD00-0AB0 is a SIMATIC DP analog input module designed for the ET 200S distributed I/O system, providing precise acquisition of analog signals from field sensors and transmitters. With four analog input channels, it is optimized for industrial process monitoring, enabling accurate measurement of voltage or current signals in automation applications such as manufacturing, energy systems, and process control.
The Siemens 6ES7134-7TD00-0AB0 uses an integrating Sigma-Delta measurement principle to ensure high stability and strong noise immunity. Its built-in interference suppression, high signal accuracy, and robust electrical characteristics make it suitable for demanding industrial environments where reliable multi-channel analog data acquisition is required.
The primary function of the Siemens 6ES7134-7TD00-0AB0 is to convert analog signals from field devices into digital values for processing within PLC and distributed control systems.
Key functions include:
Compared with conventional multi-channel analog input modules, the Siemens 6ES7134-7TD00-0AB0 provides higher measurement stability, stronger noise suppression, and improved long-distance signal handling.
1. High Measurement Stability with Sigma-Delta Technology
The Siemens 6ES7134-7TD00-0AB0 uses an integrating Sigma-Delta principle, delivering more stable readings than traditional ADC-based modules.
2. Excellent Noise Immunity
Built-in 50/60 Hz interference suppression significantly reduces electrical noise effects compared to standard analog input modules.
3. High Channel Efficiency
With four analog input channels in a compact module, the Siemens 6ES7134-7TD00-0AB0 improves system density and reduces hardware requirements.
4. Long Cable Support
Supporting shielded cable lengths up to 500 m, the Siemens 6ES7134-7TD00-0AB0 is suitable for large-scale distributed installations.
5. Low Temperature Drift
With a temperature error of only ±0.005 %/K, it offers more stable long-term measurement performance than many competing modules.
6. Strong ET 200S Integration
Designed specifically for Siemens ET 200S systems, the Siemens 6ES7134-7TD00-0AB0 ensures seamless configuration and reliable operation in distributed automation architectures.
Q1: How many input channels does 6ES7134-7TD00-0AB0 provide?
A: The Siemens 6ES7134-7TD00-0AB0 provides four analog input channels for industrial signal acquisition.
Q2: What measurement technology does 6ES7134-7TD00-0AB0 use?
A: The Siemens 6ES7134-7TD00-0AB0 uses an integrating Sigma-Delta measurement principle for high accuracy and stability.
Q3: Is 6ES7134-7TD00-0AB0 suitable for noisy industrial environments?
A: Yes, the Siemens 6ES7134-7TD00-0AB0 includes 50/60 Hz interference suppression and low crosstalk to ensure reliable operation in electrically noisy environments.
Q4: What is the maximum cable length supported by 6ES7134-7TD00-0AB0?
A: The Siemens 6ES7134-7TD00-0AB0 supports shielded cable lengths up to 500 meters.
Q5: What applications commonly use 6ES7134-7TD00-0AB0?
A: The Siemens 6ES7134-7TD00-0AB0 is widely used in process control, manufacturing systems, energy monitoring, and industrial automation applications requiring accurate analog measurements.
