Product Name: SIMATIC DP ET 200 PRO 8DI 24 VDC Electronic Module
Brand Name: Siemens
Model Number: 6ES7141-4BF00-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| Product Name | Siemens 6ES7141-4BF00-0AA0 SIMATIC DP ET 200 PRO 8DI 24 VDC Electronic Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200 PRO 8DI 24 VDC Electronic Module |
| Part Number | 6ES7141-4BF00-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Inputs | 8 |
| Input Voltage (Rated) | 24 V DC |
| Input Voltage for Signal "0" | -3 to +5 V |
| Input Voltage for Signal "1" | 13 to 30 V |
| Input Current (Signal "1") | Typical 7 mA |
| Simultaneously Controllable Inputs | 8 (up to 55 °C) |
| Address Space | 1 byte per module |
| Supply Voltage | 24 V DC |
| Reverse Polarity Protection | Yes |
| Supply Current from 1L+ | Max. 20 mA |
| Backplane Bus Supply | 3.3 V DC |
| Backplane Bus Current | Max. 20 mA |
| Sensor Supply Outputs | 8 |
| Sensor Supply Short-circuit Protection | Electronic, per module |
| Sensor Supply Output Current | Max. 1 A (up to 55 °C) |
| Typical Power Loss | 2.5 W |
| Supported Sensor Type | 2-wire sensor |
| Maximum Quiescent Current (2-wire Sensor) | 1.5 mA |
| Maximum Unshielded Cable Length | 30 m |
| Diagnostics Function | Yes |
| Diagnostic Alarm | Yes |
| Diagnostic Information Readable | Yes |
| Short-circuit Diagnostics | Yes (Sensor supply to M, per module) |
| LED Indicators | SF (red), Digital Input Status (green, per channel) |
| Potential Isolation | Between backplane bus and all other circuits |
| Channel-to-Channel Isolation | No |
| Channel-to-Backplane Isolation | Yes |
| Dielectric Test Voltage | 707 V DC (type test) |
| Isochronous Mode | Not supported |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
High-Speed Digital Input Acquisition
Provides 8 digital input channels for accurate monitoring of sensors, switches, and other field devices. The compact design enables efficient signal collection while optimizing control cabinet space.
Integrated Diagnostic Functions
Continuously monitors module status and sensor supply conditions through built-in diagnostics. Diagnostic alarms and readable status information help maintenance personnel quickly identify faults and reduce system downtime.
Reliable Sensor Supply Protection
Features electronic short-circuit protection for the integrated sensor supply outputs, helping protect connected devices from wiring faults while maintaining stable system operation.
Industrial-Grade Electrical Isolation
Offers electrical isolation between the backplane bus and field circuits to improve noise immunity, enhance signal integrity, and ensure reliable performance in demanding industrial environments.
Easy System Integration
Designed specifically for SIMATIC DP ET 200 PRO distributed I/O systems, allowing straightforward installation, efficient system expansion, and simplified maintenance.
Ideal for Industrial Automation
Well suited for factory automation, packaging machinery, conveyor systems, automotive manufacturing, process control, and other industrial applications that require reliable digital input monitoring.
Q1: What is the 6ES7141-4BF00-0AA0 used for?
A: The 6ES7141-4BF00-0AA0 is an 8-channel digital input module designed for SIMATIC DP ET 200 PRO distributed I/O systems. It is used to acquire 24 V DC digital signals from field devices such as sensors, limit switches, and push buttons in industrial automation applications.
Q2: How many digital input channels does the 6ES7141-4BF00-0AA0 provide?
A: The 6ES7141-4BF00-0AA0 provides 8 digital input channels, allowing multiple field devices to be monitored simultaneously while ensuring reliable signal acquisition.
Q3: Does the 6ES7141-4BF00-0AA0 support diagnostic functions?
A: Yes. The 6ES7141-4BF00-0AA0 includes integrated diagnostic functions, such as diagnostic alarms, readable diagnostic information, and sensor supply short-circuit detection, making troubleshooting faster and more efficient.
Q4: What types of sensors are compatible with the 6ES7141-4BF00-0AA0?
A: The 6ES7141-4BF00-0AA0 is designed to support 2-wire sensors and provides integrated sensor supply outputs with electronic short-circuit protection for dependable field operation.
Q5: Does the 6ES7141-4BF00-0AA0 provide electrical isolation?
A: Yes. The 6ES7141-4BF00-0AA0 provides electrical isolation between the backplane bus and field circuits, helping improve noise immunity and overall system reliability.
Q6: Which industrial applications are suitable for the 6ES7141-4BF00-0AA0?
A: The 6ES7141-4BF00-0AA0 is widely used in factory automation, machine building, packaging equipment, conveyor systems, automotive production lines, and process control applications requiring reliable digital input monitoring.
