Product Name: SIMATIC DP ET 200X DO 8×24 VDC/0.5A Digital Output Module
Brand Name: Siemens
Model Number: 6ES7142-1BD40-0XA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7142-1BD40-0XA0 SIMATIC DP ET 200X DO 8×24 VDC/0.5A Digital Output Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200X DO 8×24 VDC/0.5A Digital Output Module |
| Part Number | 6ES7142-1BD40-0XA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Digital Outputs | 8 |
| Output Type | Digital Output (DO) |
| Rated Load Voltage | 24 V DC |
| Output Current | 0.5 A per channel |
| Short-Circuit Protection | Yes |
| Reverse Polarity Protection | Yes |
| Output Delay (0→1 / 1→0) | Typical 0.5 ms |
| Switching Frequency | Up to 100 Hz |
| Power Loss | Approx. 3 W |
| Current Consumption | From Load Voltage L+ and Backplane Bus |
| Isolation | Galvanic isolation between outputs and backplane bus |
| Diagnostic Functions | Yes |
| Status Indicators | LED Status Indicators for Outputs |
| Protection Rating | IP65 / IP66 / IP67 (Installed in ET 200X Station) |
| Operating Temperature | -25 °C to +55 °C |
| Storage Temperature | -40 °C to +70 °C |
| Mounting | ET 200X Distributed I/O Station |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7142-1BD40-0XA0 SIMATIC DP ET 200X DO 8×24 VDC/0.5A Digital Output Module is an 8-channel 24 V DC digital output module designed for the SIMATIC ET 200X distributed I/O system. Each output delivers up to 0.5 A, making it suitable for controlling industrial actuators, relays, and other field devices. With integrated diagnostics, short-circuit and reverse polarity protection, galvanic isolation, and IP65/IP66/IP67 protection when installed, it provides reliable performance in demanding industrial environments.
Compared with similar digital output modules, the Siemens 6ES7142-1BD40-0XA0 offers robust protection, dependable output performance, and seamless ET 200X integration.
Q1: What is the 6ES7142-1BD40-0XA0 used for?
A1: 6ES7142-1BD40-0XA0 is used to provide digital output control for actuators, relays, and other field devices in SIMATIC ET 200X distributed I/O systems.
Q2: How many outputs does the 6ES7142-1BD40-0XA0 provide?
A2: 6ES7142-1BD40-0XA0 provides 8 digital output channels.
Q3: What is the output voltage and current of the 6ES7142-1BD40-0XA0?
A3: 6ES7142-1BD40-0XA0 operates at 24 V DC with a maximum output current of 0.5 A per channel.
Q4: Does the 6ES7142-1BD40-0XA0 include short-circuit protection?
A4: 6ES7142-1BD40-0XA0 includes integrated short-circuit protection for improved operational safety.
Q5: Does the 6ES7142-1BD40-0XA0 provide diagnostic functions?
A5: 6ES7142-1BD40-0XA0 features built-in diagnostics and LED status indicators for output monitoring.
Q6: What protection rating does the 6ES7142-1BD40-0XA0 offer?
A6: 6ES7142-1BD40-0XA0 provides IP65/IP66/IP67 protection when installed in an ET 200X station.
