Siemens 6ES7142-6BF50-0AB0 robust digital output module Original new

Siemens 6ES7142-6BF50-0AB0 robust digital output module Original new

Product Name:robust digital output module

Brand Name:SIEMENS

Model Number:6ES7142-6BF50-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7142 6bf50 0ab0 robust digital output module original new-1

Overview
Contact for quotatio
Specifications
Description
Applications
Environment and Certification
Technical Summary
FAQ
Spares
Recommended Products

Overview

Brand Name:	SIEMENS
Model Number:	6ES7142-6BF50-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotatio

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7142-6BF50-0AB0: Siemens ET 200eco PN distributed digital output module for decentralized machine-level automation and field I/O control
Manufacturer	Siemens: Global industrial automation leader providing PLC, I/O, and PROFINET-based control solutions
Product Type	Digital Output Module: 8-channel switching unit for 24 V DC industrial actuator control
Output Channels	8 DO: Provides grouped digital outputs for efficient multi-actuator control
Output Voltage	24 V DC: Stable industrial-grade output supply with reverse polarity protection
Output Current	0.5 A per channel: Suitable for solenoids, relays, and small industrial loads
Communication	PROFINET IO: High-speed Ethernet-based industrial communication up to 100 Mbit/s
Interface Type	M12 Connector: Rugged circular connector design for field installation
Protection Rating	IP65/IP67: Fully protected against dust, water jets, and temporary immersion
Diagnostic Function	LED & System Monitoring: Real-time fault detection including short circuit and wire break
Dimensions	30 × 200 × 49 mm: Slim distributed I/O design for machine-level installation
Weight	Approx. 550 g: Compact yet robust industrial module construction
Installation Method	Direct Machine Mounting: Eliminates need for control cabinet housing
Operating Temperature	Industrial Range: Designed for stable operation in demanding production environments

Description

The 6ES7142-6BF50-0AB0 is a robust digital output module from the Siemens SIMATIC ET 200eco PN series, designed for decentralized automation systems requiring reliable field-level control. It provides 8-channel 24 V DC outputs with 0.5 A per channel, ensuring stable switching performance in industrial environments.

As part of the ET 200eco PN distributed I/O family, including related Siemens ET 200 modules, the 6ES7142-6BF50-0AB0 integrates seamlessly into PROFINET-based architectures. Its M12 connector design and IP65/IP67 protection make it suitable for direct machine mounting without control cabinet requirements.

This module is engineered for harsh industrial applications where space-saving design, high durability, and fast communication are essential. With built-in diagnostics, short-circuit protection, and redundant load handling capability, it ensures reliable operation in continuous production systems.

Applications

Power plants: Used for generator auxiliary control, relay actuation, and distributed monitoring of field equipment.
Substations: Enables switchgear control, signal distribution, and reliable bus system actuation in power networks.
Chemical plants: Supports process automation, valve control, and intrinsically safe field signal switching.
Steel mills: Ensures robust output control for machinery operating under high temperature and electromagnetic interference.
Machinery manufacturing: Applied in automated production lines, robotics systems, and packaging equipment control.

Environment and Certification

Industrial Protection Class: IP65/IP67 rating ensures full resistance to dust, water jets, and harsh outdoor or factory conditions.
Explosion Protection Compliance: Certified for ATEX II 3G and II 3D environments, suitable for hazardous industrial zones.
Functional Safety Standards: Supports SIL 2, PL d (Category 3), ensuring safe shutdown and reliable operation in critical systems.
EMC and Electrical Isolation: Designed with strong electrical isolation between load and communication circuits for stable operation.
PROFINET Industrial Compliance: Fully compatible with industrial Ethernet standards for secure and deterministic communication.

Technical Summary

Field-Level Decentralized Integration: With integrated PROFINET IO communication and rugged M12 industrial connectors, the module supports direct installation on machines, eliminating the need for traditional control cabinet wiring. This significantly reduces installation time, wiring complexity, and overall system cost while improving scalability in modular production lines.
Reliable Load Handling Capability: Each output channel is designed with short-circuit protection and diagnostic monitoring, ensuring safe operation during overload or wiring faults. The system supports redundant load switching, making it suitable for critical industrial processes requiring high availability.
Real-Time Diagnostic Feedback: Built-in LED indicators and diagnostic functions provide immediate status visibility, including group fault detection, wire-break monitoring, and supply voltage supervision. This allows faster troubleshooting and reduces downtime in automated production systems.

FAQ

Q1: What is the main function of 6ES7142-6BF50-0AB0?
A1: It is an 8-channel digital output module used for controlling industrial actuators in ET 200eco PN systems.

Q2: Does it support PROFINET communication?
A2: Yes, it supports PROFINET IO with up to 100 Mbit/s Ethernet communication.

Q3: What protection rating does it have?
A3: It has IP65/IP67 protection for use in harsh industrial environments.

Q4: Can it be mounted directly on machines?
A4: Yes, it is designed for decentralized installation without a control cabinet.

Q5: Is it suitable for safety-related applications?
A5: Yes, it supports SIL 2 and PL d Category 3 functional safety standards.
