Product Name: SIMATIC DP ET 200eco PN Digital Output Module
Brand Name: Siemens
Model Number: 6ES7142-6BH00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7142-6BH00-0AB0 SIMATIC DP ET 200eco PN Digital Output Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200eco PN Digital Output Module |
| Part Number | 6ES7142-6BH00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Digital Outputs | 16 |
| Output Grouping | 2 Groups of 8 Outputs |
| Rated Supply Voltage | 24 VDC |
| Load Voltage 1L+ | 24 VDC (20.4–28.8 VDC) |
| Load Voltage 2L+ | 24 VDC (20.4–28.8 VDC) |
| Reverse Polarity Protection | Yes |
| NEC Requirement | Class 2 Power Supply Required |
| Typical Current Consumption | 100 mA |
| Maximum Current from Supply Voltage 1L+ | 4 A |
| Maximum Current from Load Voltage 1L+ | 4 A |
| Maximum Current from Load Voltage 2L+ | 4 A |
| Typical Power Loss | 5.5 W |
| Rated Output Current | 1.3 A per Output |
| Residual Current (Signal "0") | Max. 1.5 mA |
| Short-Circuit Protection | Yes |
| Short-Circuit Response Threshold | Typical 1.8 A |
| Inductive Shutdown Voltage Limitation | Typical -47 V (L1+, L2+) |
| Maximum Lamp Load | 5 W |
| Redundant Load Control | Supported |
| Switching Frequency (Resistive Load) | Max. 100 Hz |
| Switching Frequency (Inductive Load) | Max. 0.5 Hz |
| Switching Frequency (Lamp Load) | Max. 1 Hz |
| Maximum Total Output Current per Group | 3.9 A (Up to 60°C) |
| Maximum Unshielded Cable Length | 30 m |
| Communication Standard | PROFINET IO |
| Transmission Protocol | 100BASE-TX |
| Number of PROFINET Interfaces | 1 |
| Maximum Transmission Rate | 100 Mbit/s |
| Test Voltage (24 VDC Circuits) | 707 VDC |
| Interface Isolation Test Voltage | 1500 Vrms (IEEE 802.3) |
| Degree of Protection | IP65 / IP67 |
| Performance Level | PL d (ISO 13849-1) |
| Safety Category | Cat. 3 (ISO 13849-1) |
| Functional Safety Rating | SIL 2 (IEC 62061) |
| Explosion Protection (Gas) | ATEX II 3G Ex nA II T4 |
| Explosion Protection (Dust) | ATEX II 3D Ex tc IIIC T90°C Dc |
| Electrical Connection | 4/5-Pin M12 Circular Connectors |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7142-6BH00-0AB0 SIMATIC DP ET 200eco PN Digital Output Module is a rugged 16-channel digital output module designed for the SIMATIC ET 200eco PN distributed I/O system. It features 16 digital outputs arranged in two groups, PROFINET IO communication, 24 VDC operating voltage, short-circuit protection, and an IP65/IP67-rated enclosure for reliable operation in harsh industrial environments. The module provides dependable control of field devices while supporting high-performance distributed automation networks. Its robust design, integrated protection features, and seamless system compatibility make it an ideal solution for factory automation, machine control, material handling, conveyor systems, and distributed I/O applications.
Digital Output Control
Controls solenoid valves, relays, contactors, indicator lamps, and other field actuators by delivering reliable digital output signals.
16-Channel Output Processing
Provides sixteen independent digital output channels organized into two output groups, enabling efficient control of multiple industrial devices.
PROFINET IO Communication
Communicates with Siemens controllers through the PROFINET IO network, ensuring fast and reliable data exchange in distributed automation systems.
Output Protection
Incorporates short-circuit protection and reverse polarity protection to improve system reliability and safeguard connected field equipment.
Distributed Field Device Control
Supports decentralized installation close to field equipment, reducing wiring complexity and improving the flexibility of industrial control system design.
Industrial Safety Integration
Supports functional safety applications with SIL 2 and Performance Level d capabilities, making it suitable for factory automation, machine safety, material handling, packaging equipment, and other safety-related industrial applications.
