Siemens 6ES7145-4FF00-0AB0 SIMATIC DP ET 200 PRO Analog Output Module

Siemens 6ES7145-4FF00-0AB0 SIMATIC DP ET 200 PRO Analog Output Module

Product Name: SIMATIC DP ET 200 PRO Analog Output Module

Brand Name: Siemens

Model Number: 6ES7145-4FF00-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7145 4ff00 0ab0 simatic dp et 200 pro analog output module -1

Overview
Specifications
Contact Us
Overview
Functions
Why Choose Us
Major Business
After-sales Service
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Product Name	Siemens 6ES7145-4FF00-0AB0 SIMATIC DP ET 200 PRO Analog Output Module
Manufacturer	Siemens
Product Type	SIMATIC DP ET 200 PRO Analog Output Module
Part Number	6ES7145-4FF00-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Analog Outputs	4
Output Signal Ranges	0 to 10 V, 1 to 5 V, -10 to +10 V
Rated Supply Voltage	24 VDC
Reverse Polarity Protection	Yes (Against Destruction)
Current Consumption (1L+)	Max. 65 mA
Backplane Bus Current	Max. 10 mA at 3.3 VDC
Typical Power Loss	1.7 W
Address Space	Max. 8 Bytes per Module
Short-Circuit Protection	Yes, Per Module
Maximum Output Current	1 A (Up to 55°C)
Maximum Short-Circuit Current	50 mA
Cycle Time (All Channels)	Max. 3 ms
Supported Output Connection	2-Wire, 4-Wire
Minimum Load Impedance	1000 Ω
Maximum Capacitive Load	1 µF
Maximum External Voltage at Outputs	16 V Permanent (Toward MANA)
Maximum Shielded Cable Length	30 m
Resolution	15 Bit (-10 to +10 V), 15 Bit (0 to 10 V), 14 Bit (1 to 5 V)
Conversion Time	0.7 ms per Channel
Settling Time (Resistive Load)	0.1 ms
Settling Time (Capacitive Load)	6 ms
Output Ripple	±0.02% of Output Range (0–50 kHz)
Linearity Error	±0.1% of Output Range
Temperature Error	±0.01%/K
Repeat Accuracy (25°C)	±0.05% of Output Range
Operational Accuracy	±0.2% of Output Range
Basic Accuracy (25°C)	±0.15% of Output Range
Diagnostic Alarm	Yes, Parameterizable
Hardware Interrupt	No
Diagnostic Information	Readable
Wire-Break Detection	No
Short-Circuit Diagnostics	Yes, Per Channel (Not in Zero Range)
Group Error LED	SF (Red)
Channel-to-Channel Isolation	No
Isolation to Backplane Bus	Yes
Isolation Test Voltage	707 VDC (Type Test)

Contact Us

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Overview

The Siemens 6ES7145-4FF00-0AB0 SIMATIC DP ET 200 PRO Analog Output Module is a high-precision 4-channel analog output module designed for the SIMATIC ET 200 PRO distributed I/O system. It features four voltage output channels, 24 VDC supply voltage, 15-bit output resolution, short-circuit protection, and backplane bus isolation to ensure accurate and reliable analog signal generation. The module delivers stable analog control signals to field devices while supporting efficient distributed automation architectures. Its high output accuracy, integrated diagnostics, and seamless compatibility with Siemens automation platforms make it an ideal solution for process automation, machine control, manufacturing, and distributed I/O applications.

Functions

Analog Voltage Output
Generates precise analog voltage signals to control actuators, variable frequency drives, control valves, and other industrial field devices.

Four-Channel Output Processing
Provides four independent analog output channels, enabling simultaneous control of multiple process variables within distributed automation systems.

High-Accuracy Signal Control
Delivers high-resolution analog outputs with excellent repeatability and linearity, ensuring stable and accurate control of industrial processes.

Output Protection and Diagnostics
Features integrated short-circuit protection and parameterizable diagnostic alarms to improve system reliability and simplify fault detection.

Distributed Process Control
Supports decentralized installation within the ET 200 PRO platform, reducing field wiring while improving system flexibility and scalability.

SIMATIC ET 200 PRO Integration
Integrates seamlessly with Siemens SIMATIC ET 200 PRO distributed I/O systems, providing dependable analog output control for process automation, factory automation, machine control, packaging equipment, and manufacturing applications.
