Product Name: SIMATIC DP ET 200ECO PN 8 DIO Digital I/O Module
Brand Name: Siemens
Model Number: 6ES7147-6BG00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7147-6BG00-0AB0 SIMATIC DP ET 200ECO PN 8 DIO Digital I/O Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200ECO PN 8 DIO Digital I/O Module |
| Part Number | 6ES7147-6BG00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Digital Inputs / Outputs | 8 DI / 8 DO (2 groups of 4) |
| Rated Output Current | 1.3 A per output |
| Connector Type | 8 × M12 connectors (4/5-pin circular connectors) |
| Protection Rating | IP65 / IP67 |
| PROFINET Interface | 1 × 100BASE-TX, M12 port with integrated switch |
| Rated Supply Voltage | 24 V DC |
| Permissible Supply Voltage Range | 20.4–28.8 V DC |
| Typical Current Consumption | 100 mA |
| Current from Supply Voltage (1L+) | Max. 4 A |
| Current from Load Voltage (1L+, Unswitched) | 4 A |
| Current from Load Voltage (2L+) | Max. 4 A |
| Encoder Supply | 24 V DC |
| Power Loss | Typical 6.5 W |
| Rated Input Voltage | 24 V DC |
| Maximum Input Cable Length | 30 m (unshielded) |
| Short-Circuit Response Threshold | Typical 1.8 A |
| Inductive Shutdown Voltage | Typical -47 V (L1+, L2+) |
| Lamp Load Capacity | Max. 5 W |
| Output Current ("1") | Rated/Maximum 1.3 A |
| Residual Current ("0") | Max. 1.5 mA |
| Total Output Current (per Group) | Max. 3.9 A (@ ≤60°C) |
| Maximum Output Cable Length | 30 m (unshielded) |
| Maximum Sensor Quiescent Current | 1.5 mA |
| Transmission Standard | 100BASE-TX Ethernet |
| Maximum Transmission Rate | 100 Mbit/s |
| Supported Protocol | PROFINET IO |
| Isolation Voltage (24 V DC Circuits) | 707 V DC (type test) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7147-6BG00-0AB0 SIMATIC DP ET 200ECO PN 8 DIO Digital I/O Module is a rugged IP65/IP67 distributed I/O module featuring 8 digital inputs and 8 digital outputs for PROFINET-based automation systems. Equipped with integrated PROFINET communication, M12 industrial connectors, and output currents of up to 1.3 A per channel, it provides reliable field-level control without the need for additional control cabinets. Its compact design, built-in Ethernet switch, and comprehensive protection functions make it ideal for demanding industrial environments.
Compared with similar distributed digital I/O modules, the Siemens 6ES7147-6BG00-0AB0 offers higher environmental protection, integrated networking, and simplified field installation.
Q1: What is the 6ES7147-6BG00-0AB0 used for?
A1: 6ES7147-6BG00-0AB0 is used for distributed digital input and output control in PROFINET industrial automation systems.
Q2: How many digital inputs and outputs does the 6ES7147-6BG00-0AB0 provide?
A2: 6ES7147-6BG00-0AB0 provides 8 digital inputs and 8 digital outputs.
Q3: What communication protocol does the 6ES7147-6BG00-0AB0 support?
A3: 6ES7147-6BG00-0AB0 supports PROFINET IO with a 100BASE-TX Ethernet interface.
Q4: What is the output current of the 6ES7147-6BG00-0AB0?
A4: 6ES7147-6BG00-0AB0 provides up to 1.3 A of rated output current per channel.
Q5: What protection rating does the 6ES7147-6BG00-0AB0 have?
A5: 6ES7147-6BG00-0AB0 is rated IP65/IP67, making it suitable for harsh industrial environments.
Q6: What type of connectors are used on the 6ES7147-6BG00-0AB0?
A6: 6ES7147-6BG00-0AB0 uses 8 M12 4/5-pin circular connectors for field device connections.
