Product Name: SIMATIC DP ET 200PRO Pneumatic Interface/ Digital Output Module
Brand Name: Siemens
Model Number: 6ES7148-4EA00-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7148-4EA00-0AA0 SIMATIC DP ET 200PRO Pneumatic Interface/ Digital Output Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200PRO Pneumatic Interface/ Digital Output Module |
| Part Number | 6ES7148-4EA00-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Bus Module | Included |
| Number of Digital Outputs | 16 |
| Maximum Connectable Valves | 16 |
| Rated Load Voltage 2L+ | 24 V DC |
| Short-Circuit Protection | Yes |
| Reverse Polarity Protection | Yes |
| Maximum Current from 2L+ | 300 mA, including valves |
| Backplane Bus Current | Max. 25 mA @ 3.3 V DC |
| Typical Power Loss | 2.6 W |
| Maximum Address Space | 2 Bytes |
| Load Resistance Range | 500–2,500 Ω |
| Rated Output Current for Signal "1" | 12 mA |
| Permissible Output Current for Signal "1" | 11–15 mA |
| Maximum Switching Frequency | 25 Hz with inductive load |
| Maximum Total Output Current | 250 mA up to 55°C; limited by valves to 50°C |
| Minimum Working Pressure | 3 bar |
| Maximum Working Pressure | 8 bar |
| Rated Flow Rate | 400 L/min |
| Valve Switching Time (0 → 1) | 17 ms |
| Valve Switching Time (1 → 0) | 25 ms |
| Group Error Indicator | SF, Red LED |
| Digital Output Status Indicator | Green LED |
| Diagnostic Parameter | Load Voltage 2L+ |
| Response to CPU/Master STOP | No |
| Backplane Bus Isolation | Yes, isolated from all other circuit components |
| Digital Output to Backplane Bus Isolation | Yes |
| Isolation Test Voltage | 707 V DC (Type Test) |
| Safety-Related Tripping | Suitable for safety-related tripping of standard modules |
| Performance Level | PL d according to ISO 13849-1 |
| Safety Category | Category 3 according to ISO 13849-1 |
| Safety Integrity Level | SIL 2 according to IEC 62061 |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7148-4EA00-0AA0 SIMATIC DP ET 200PRO Pneumatic Interface/Digital Output Module is a combined pneumatic interface and 16-channel digital output module designed for decentralized automation with the SIMATIC ET 200PRO platform. It supports connection and control of up to 16 pneumatic valves, operates with a 24 VDC load supply, and provides a rated pneumatic flow of 400 L/min across a 3 to 8 bar working pressure range. Integrated short-circuit and reverse-polarity protection, output status LEDs, load-voltage diagnostics, and electrical isolation help ensure dependable operation and simplify troubleshooting. The module also supports safety-related tripping up to PL d, Category 3, and SIL 2, making it suitable for machine automation applications requiring coordinated electrical and pneumatic control.
The Siemens 6ES7148-4EA00-0AA0 is designed for controlling pneumatic valves and actuators directly within distributed automation systems. With up to 16 valve connections and switching times of approximately 17 ms for activation and 25 ms for deactivation, it is well suited for pneumatic cylinders, grippers, positioning mechanisms, sorting devices, clamping equipment, and other air-operated actuators used in automated machinery.
As part of the SIMATIC ET 200PRO platform, the module is particularly suitable for packaging machinery, assembly lines, conveyor and material handling systems, automotive production, robotic cells, and general factory automation. Its combination of digital output control, pneumatic interfacing, diagnostics, and safety-related tripping capability helps reduce separate components and wiring while enabling reliable decentralized control close to the machine or production process.
