Product Name: SIMATIC DP ET 200S IM151-3 PN HF PROFINET Interface Module
Brand Name: Siemens
Model Number: 6ES7151-3BA22-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7151-3BA22-0AB0 SIMATIC DP ET 200S IM151-3 PN HF PROFINET Interface Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200S IM151-3 PN HF PROFINET Interface Module |
| Part Number | 6ES7151-3BA22-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Communication Protocol | PROFINET IO, TCP/IP |
| Transmission Standard | 100BASE-TX |
| Data Transmission Rate | 10 Mbps (Ethernet Services); 100 Mbps Full Duplex (PROFINET IO) |
| PROFINET Interfaces | 2 × RJ45 Ethernet Ports |
| Supported Ethernet Services | Ping, ARP, SNMP (MIB-II Network Diagnostics) |
| Rated Supply Voltage | 24 V DC |
| Reverse Polarity Protection | Yes |
| Power Failure Buffer Time | Minimum 20 ms |
| Current Consumption | Approx. 200 mA |
| Power Dissipation | Approx. 2 W |
| Permissible Potential Difference | 75 V DC / 60 V AC |
| Insulation Test Voltage | 500 V DC |
| Interrupt Capability | Yes |
| Diagnostic Functions | Yes |
| Status Indicators | SF (Red), BF (Red), ON (Green), LINK (Green per Port), RX/TX (Green per Port) |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7151-3BA22-0AB0 SIMATIC DP ET 200S IM151-3 PN HF PROFINET Interface Module is a high-performance PROFINET interface module designed for the SIMATIC ET 200S distributed I/O system. It supports PROFINET IO and TCP/IP communication, featuring dual RJ45 Ethernet ports with transmission speeds of up to 100 Mbps full duplex. With integrated diagnostics, interrupt capability, and comprehensive status indicators, the module enables reliable, high-speed communication and efficient network management in industrial automation applications.
Compared with similar PROFINET interface modules, the Siemens 6ES7151-3BA22-0AB0 offers high-speed communication, advanced diagnostics, and reliable ET 200S integration.
Q1: What is the 6ES7151-3BA22-0AB0 used for?
A1: 6ES7151-3BA22-0AB0 is used to provide PROFINET communication for SIMATIC ET 200S distributed I/O stations.
Q2: Which communication protocols does the 6ES7151-3BA22-0AB0 support?
A2: 6ES7151-3BA22-0AB0 supports PROFINET IO and TCP/IP communication.
Q3: How many Ethernet ports does the 6ES7151-3BA22-0AB0 provide?
A3: 6ES7151-3BA22-0AB0 features two RJ45 Ethernet ports.
Q4: What is the maximum communication speed of the 6ES7151-3BA22-0AB0?
A4: 6ES7151-3BA22-0AB0 supports 100 Mbps full-duplex communication for PROFINET IO.
Q5: Does the 6ES7151-3BA22-0AB0 include diagnostic functions?
A5: 6ES7151-3BA22-0AB0 includes integrated diagnostics and supports network services such as Ping, ARP, and SNMP.
Q6: What power supply does the 6ES7151-3BA22-0AB0 require?
A6: 6ES7151-3BA22-0AB0 operates with a 24 V DC rated supply voltage and includes reverse polarity protection.
