Product Name: ET 200S IM151-8F PN/DP Fail-safe CPU Interface Module
Brand Name: Siemens
Model Number: 6ES7151-8FB00-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7151-8FB00-0AB0 ET 200S IM151-8F PN/DP Fail-safe CPU Interface Module |
| Manufacturer | Siemens |
| Product Type | ET 200S IM151-8F PN/DP Fail-safe CPU Interface Module |
| Part Number | 6ES7151-8FB00-0AB0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated Supply Voltage | 24 V DC |
| Supply Voltage Range | 20.4 to 28.8 V DC |
| Reverse Polarity Protection | Yes |
| Power Failure Buffer Time | 5 ms |
| Maximum Inrush Current | 1.8 A |
| Maximum Supply Current | 380 mA (460 mA with DP Master Module) |
| Backplane Bus Output Current | Max. 700 mA (5 V DC) |
| Typical Power Dissipation | 5.5 W |
| Integrated Work Memory | 192 KB |
| Retentive Memory | 64 KB |
| Maximum Program Blocks | 1,024 |
| Maximum Data Blocks (DB) | 511 (64 KB each) |
| Maximum Function Blocks (FB) | 1,024 |
| Maximum Functions (FC) | 1,024 |
| Maximum Local Data | 510 Bytes per Priority Class |
| I/O Address Space | 2,048 Bytes Inputs / 2,048 Bytes Outputs |
| Maximum Central Modules | 63 ET 200S Modules |
| Maximum Station Width | ≤ 1 m or < 2 m |
| PROFINET Interface | 1 Integrated Interface |
| Ethernet Ports | 3 × RJ45 |
| PROFINET Transmission Rate | 100 Mbit/s Full Duplex |
| Electrical Isolation | 500 V DC Tested |
| Permissible Potential Difference | 75 V DC / 60 V AC |
| Degree of Protection | IP20 |
| Configuration Software | STEP 7 V5.4 SP4 or Later |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7151-8FB00-0AB0 ET 200S IM151-8F PN/DP Fail-safe CPU Interface Module is a fail-safe CPU and interface module for the SIMATIC ET 200S distributed I/O system. It combines high-performance PLC functionality with PROFINET and PROFIBUS DP communication, making it ideal for safety-related automation applications. Featuring 192 KB of integrated work memory, three RJ45 Ethernet ports, and support for up to 63 ET 200S modules, it delivers reliable machine control, safety processing, and flexible network integration.
Compared with similar fail-safe CPU interface modules, the Siemens 6ES7151-8FB00-0AB0 offers integrated safety control, high-performance communication, and scalable ET 200S expansion.
Q1: How many Ethernet ports are available on the 6ES7151-8FB00-0AB0?
A1: 6ES7151-8FB00-0AB0 features three integrated RJ45 Ethernet ports for PROFINET communication.
Q2: What is the maximum PROFINET communication speed of the 6ES7151-8FB00-0AB0?
A2: 6ES7151-8FB00-0AB0 supports 100 Mbps full-duplex PROFINET communication.
Q3: What is the supply voltage of the 6ES7151-8FB00-0AB0?
A3: 6ES7151-8FB00-0AB0 operates on 24 V DC with a permissible supply voltage range of 20.4 to 28.8 V DC.
Q4: What level of electrical protection does the 6ES7151-8FB00-0AB0 provide?
A4: 6ES7151-8FB00-0AB0 features reverse polarity protection and 500 V DC tested electrical isolation for reliable industrial operation.
Q5: What are the main benefits of the 6ES7151-8FB00-0AB0?
A5: 6ES7151-8FB00-0AB0 provides integrated fail-safe PLC control, high-speed PROFINET and PROFIBUS communication, large memory capacity, scalable ET 200S expansion, reliable industrial protection, and efficient configuration with STEP 7 software.
