Product Name:8 S7-300 MODULES
Brand Name:Siemens
Model Number:6ES7153-2AA02-0XB0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7153-2AA02-0XB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 6ES7153-2AA02-0XB0 |
| System Type | ET 200M DP Interface Module |
| Communication | PROFIBUS DP (RS485) |
| Max Modules Supported | Up to 8 S7-300 modules |
| Supply Voltage | 24 V DC (20.4–28.8 V) |
| Power Loss | ~5 W |
| Backplane Output | 5 V DC / max. 1 A |
| Input Current | Max. 550 mA |
| Transmission Rate | Up to 12 Mbit/s |
| Protection Class | IP20 |
| Operating Temp. | 0 to 60 °C |
| Dimensions | 40 × 125 × 117 mm |
| Weight | Approx. 360 g |
The 6ES7153-2AA02-0XB0 is a SIMATIC DP ET 200M interface module designed for high-performance distributed I/O systems based on PROFIBUS DP architecture. It supports integration of up to 8 S7-300 I/O modules per slave interface, delivering flexible and scalable automation solutions for complex industrial environments.
Engineered with redundancy support and precise time-stamping functionality, the 6ES7153-2AA02-0XB0 ensures reliable signal processing and accurate event tracking with millisecond-level resolution. Its RS485-based PROFIBUS DP interface enables stable high-speed communication up to 12 Mbit/s, making it suitable for demanding process control applications.
With robust IP20 protection, low power consumption, and strong resistance to electrical interference, this interface module is widely used in mission-critical automation systems requiring continuous operation and data integrity.
Q1: What is the main function of 6ES7153-2AA02-0XB0?
A1: It acts as an ET 200M interface module connecting S7-300 I/O modules to PROFIBUS DP networks.
Q2: How many modules can it support?
A2: It supports up to 8 S7-300 I/O modules per interface station.
Q3: Does it support redundancy?
A3: Yes, it is designed with redundancy capability for high system reliability.
Q4: What communication protocol does it use?
A4: It uses PROFIBUS DP based on RS485 communication standard.
Q5: What industries commonly use this module?
A5: It is widely used in power plants, substations, steel mills, and industrial automation systems.
|
