Siemens 6ES7153-2BA82-0XB0 SIMATIC DP, INTERFACE DP/PA-LINK Original new

Siemens 6ES7153-2BA82-0XB0 SIMATIC DP, INTERFACE DP/PA-LINK Original new

Product Name:SIMATIC DP, INTERFACE DP/PA-LINK

Brand Name:Siemens

Model Number:6ES7153-2BA82-0XB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7153-2BA82-0XB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Item	Specification
Product Model	6ES7153-2BA82-0XB0
Product Type	ET200M IM153-2 HF DP Interface Module
Supply Voltage	24 V DC (20.4–28.8 V DC)
Power Loss	~5.5 W
Backplane Output	5 V DC, max. 1.5 A
PROFIBUS Speed	Up to 12 Mbit/s
I/O Capacity	244 bytes inputs / 244 bytes outputs
Module Capacity	Up to 12 S7-300 modules
Time Stamp Accuracy	1 ms (up to 8 modules), 10 ms (up to 12)
Communication	PROFIBUS DP (EN 50170)
Dimension (H×W×D)	125 × 40 × 117 mm
Weight	~360 g
Operating Temperature	-25 °C to +60 °C

Description

The 6ES7153-2BA82-0XB0 SIMATIC DP IM153-2 HF is a high-performance PROFIBUS DP interface module designed for ET200M distributed I/O systems. It supports integration of up to 12 S7-300 I/O modules and is optimized for extended temperature operation, redundancy applications, and time-critical industrial automation environments.

The 6ES7153-2BA82-0XB0 provides advanced features such as time stamping, isochronous mode support, and expanded HART variable handling. With a robust PROFIBUS DP slave interface, it ensures fast and reliable communication in complex process control architectures.

Engineered for demanding industrial conditions, the 6ES7153-2BA82-0XB0 delivers stable performance, precise signal synchronization, and flexible system expansion, making it ideal for modern distributed automation and safety-critical control systems.

Applications

Power plants: Used for generator set status monitoring and relay protection.
Substations: Enable bus differential control, line protection, and switchyard signal acquisition.
Chemical plants: Integrate process control automation and intrinsically safe signal monitoring.
Steel mills (metallurgical plants): Perform high-temperature and EMI-resistant control operations.
Machinery manufacturing plants: Used for automated production lines, robotics, and packaging systems.

Features

Supports up to 12 S7-300 modules per station
High-speed PROFIBUS DP communication up to 12 Mbit/s
Integrated time stamping with millisecond precision
Redundancy-capable industrial interface design
Extended temperature range for harsh environments
HART and advanced diagnostic support

Functions

Distributed I/O signal processing
Real-time data communication via PROFIBUS DP
Event time stamping and alarm handling
System synchronization in isochronous mode
Slave-to-slave data exchange support
Modular system expansion and configuration

FAQ

Q1: What is 6ES7153-2BA82-0XB0 used for?
A1: It is used as a PROFIBUS DP interface module for ET200M distributed I/O systems.

Q2: How many modules can it support?
A2: It can handle up to 12 S7-300 modules per DP slave interface.

Q3: Does it support redundancy?
A3: Yes, it is designed with redundancy capability for critical applications.

Q4: What communication protocol does it use?
A4: It uses PROFIBUS DP based on EN 50170 standard.

Q5: What industries commonly use this module?
A5: It is widely used in power plants, substations, chemical plants, and heavy industry automation systems.
