Product Name: SIMATIC DP IM157 Interface Module
Brand Name: Siemens
Model Number: 6ES7157-0AA82-0XA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7157-0AA82-0XA0 SIMATIC DP IM157 Interface Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP IM157 Interface Module |
| Part Number | 6ES7157-0AA82-0XA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Description | DP/PA Link Coupler Module |
| System Function | The IM157 and one or more DP/PA Couplers form the DP/PA Link |
| DPV1 Role | DPV1 Slave |
| DP Master Parameter Assignment Telegram Length | 244 bytes |
| Power Supply | Via Bus Module |
| Communication Interface | PROFIBUS DP |
| Lower-Level DP Master Transmission Rate | 45.45 kbit/s to 12 Mbit/s (Max. 12 Mbit/s) |
| Bus Termination | Active Terminating Resistor (Bus Terminator) |
| OLM/OBT Support | Yes |
| Maximum RS 485 Repeaters | 8 |
| Maximum DP Slaves | 31 (64 with RS 485 Repeaters or OLM/OBT) |
| Supported Protocol | PROFIBUS DP |
| Status Indicator | No |
| Alarms | No |
| Diagnostic Functions | Yes |
| Potential Isolation | Yes, to Lower-Level DP Master System |
|
Sales |
|
Phone/Whatsapp |
|
Jim Pei |
The Siemens 6ES7157-0AA82-0XA0 SIMATIC DP IM157 Interface Module is a high-performance DP/PA Link interface module designed to integrate PROFIBUS DP and PROFIBUS PA networks within Siemens SIMATIC automation systems. It operates as a DPV1 slave and, together with one or more DP/PA Couplers, forms a complete DP/PA Link for seamless communication between field devices and higher-level control systems. Featuring support for transmission rates up to 12 Mbit/s, diagnostic functions, potential isolation, and compatibility with RS485 repeaters and optical link modules, the module delivers reliable communication, simplified network integration, and stable long-term operation. It is an ideal solution for process automation applications in chemical, oil and gas, pharmaceutical, water treatment, and power generation industries.
DP/PA Network Integration
Works together with Siemens DP/PA Couplers to establish a DP/PA Link, enabling seamless communication between PROFIBUS DP control networks and PROFIBUS PA field devices.
PROFIBUS DP Communication
Acts as a DPV1 slave, ensuring reliable data exchange between distributed field instruments and higher-level PLC or DCS controllers.
Field Device Connectivity
Provides an efficient communication interface for connecting intelligent process instruments such as transmitters, valves, analyzers, and other PROFIBUS PA devices.
Network Expansion Support
Supports the use of RS485 repeaters, Optical Link Modules (OLM), and Optical Bus Terminals (OBT), allowing flexible network expansion over longer communication distances.
Diagnostic and Fault Detection
Offers integrated diagnostic capabilities that enable rapid identification of communication issues, reducing troubleshooting time and improving system availability.
Electrical Isolation Protection
Provides galvanic isolation between the interface module and the lower-level DP master system, enhancing communication stability and protecting connected automation equipment from electrical interference.
