Siemens 6ES7193-6BP00-0DA0 SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D Original new

Siemens 6ES7193-6BP00-0DA0 SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D Original new

Product Name:SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D

Brand Name:Siemens

Model Number:6ES7193-6BP00-0DA0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7193 6bp00 0da0 simatic et 200sp baseunit bu15 p16a02d original new-1

Overview
Inquiry now
Specifications
Description
Applications
Control & Communication
Environment and Certification
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7193-6BP00-0DA0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7193-6BP00-0DA0
Product Type	SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D
Slot Type	Type A0, 1 slot
Terminal Type	Push-in terminals
Supply Voltage	24 V DC
Process Terminals	16
AUX Terminals	None
Potential Group	New potential group
Maximum Bus Current	P1/P2 Bus: 10 A
Maximum Process Terminal Current	2 A
Conductor Size	0.14–2.5 mm² (AWG 26–14)
Operating Temperature	-30°C to +60°C (horizontal), -30°C to +50°C (vertical)
Maximum Installation Altitude	5,000 m
Shield Connection	Integrated, optional
Isolation Voltage	707 V DC (type tested)
Dimensions	15 × 117 × 35 mm (W × H × D)
Weight	Approx. 40 g

Description

Siemens 6ES7193-6BP00-0DA0 is a SIMATIC ET 200SP BaseUnit BU15-P16+A0+2D designed to provide a reliable electrical interface for distributed I/O systems in industrial automation. Featuring push-in terminals, a new potential group configuration, and a compact 15 mm design, it enables fast installation while supporting secure and organized field wiring.

Compatible with SIMATIC ET 200SP I/O modules and other 6ES7193 BaseUnit variants, the 6ES7193-6BP00-0DA0 simplifies module replacement and system expansion without increasing cabinet space. Its integrated power bus connections and robust terminal architecture improve wiring efficiency and long-term operational stability.

Designed for factory automation, process control, and machine-building applications, this BaseUnit delivers dependable connectivity, simplified maintenance, and flexible integration for modern PLC-based control systems.

Applications

Power plants: Provides secure BaseUnit installation for distributed I/O systems used in generator monitoring, auxiliary equipment control, and relay interfaces.
Substations: Supports reliable field wiring for protection relays, switchgear automation, and signal acquisition cabinets.
Chemical plants: Enables stable distributed control connections for process instrumentation and hazardous-area automation systems.
Steel mills: Delivers dependable module mounting and electrical connectivity in high-temperature and high-EMI production environments.
Machinery manufacturing plants: Simplifies PLC cabinet assembly for automated production lines, robotic cells, and packaging equipment.
Water treatment facilities: Supports decentralized control stations for pumps, valves, and monitoring instruments.
Industrial automation systems: Ideal for modular control panels requiring compact installation, fast wiring, and scalable ET 200SP expansion.

Control & Communication

Supports reliable electrical interfaces for SIMATIC ET 200SP distributed I/O architectures.
Push-in connection technology speeds field wiring while ensuring secure conductor retention.
Creates a new isolated potential group for improved electrical organization.
Provides stable power distribution through the integrated P1/P2 backplane bus.
Supports up to 16 process terminals for flexible module connectivity.
Optional integrated shield connection improves EMC performance in industrial environments.
Designed for rapid module replacement and efficient cabinet maintenance without rewiring adjacent components.

Environment and Certification

Operates reliably from -30°C to +60°C in horizontal installations.
Supports vertical installation up to +50°C while maintaining stable performance.
Suitable for installation at elevations up to 5,000 meters with specified operating restrictions.
Integrated mains filtering enhances electrical reliability in industrial control systems.
Type-tested insulation rated at 707 V DC for dependable electrical isolation.
Includes an Environmental Product Declaration (EPD) supporting sustainable industrial projects.
Designed according to Siemens industrial quality standards for long-term operation in demanding automation applications.

FAQ

Q1: What is the primary purpose of the 6ES7193-6BP00-0DA0 BaseUnit?
A1: It provides the mounting base, electrical interface, and wiring connections for compatible SIMATIC ET 200SP I/O modules.

Q2: Does the 6ES7193-6BP00-0DA0 support push-in wiring technology?
A2: Yes. It features push-in terminals that simplify installation and reduce wiring time.

Q3: How many process terminals are available on this BaseUnit?
A3: The unit provides 16 process terminals for field signal connections.

Q4: What operating environments is the 6ES7193-6BP00-0DA0 designed for?
A4: It is intended for industrial automation applications including manufacturing, process control, utilities, and distributed PLC systems.

Q5: Is the 6ES7193-6BP00-0DA0 compatible with other SIMATIC ET 200SP modules?
A5: Yes. It is designed to integrate seamlessly with compatible SIMATIC ET 200SP I/O modules, supporting flexible system expansion and simplified maintenance.
