Siemens 6ES7212-1HE40-0XB0 SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU

Siemens 6ES7212-1HE40-0XB0 SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU

Product Name: SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU

Brand Name: Siemens

Model Number: 6ES7212-1HE40-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Specifications
Commercial Terms
Description
Functions
Why Choose US
FAQ
Other Products
Recommended Products

Contact Info

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7212-1HE40-0XB0 SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU
Manufacturer	Siemens
Product Type	SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU
Part Number	6ES7212-1HE40-0XB0
Place of shipment	Xiamen, China
Country of origin	Germany
Power Supply	24 VDC
Input Voltage Range	20.4–28.8 VDC
Load Voltage (L+)	24 VDC
Rated Input Current	400 mA (CPU only)
Maximum Input Current	1.2 A (CPU with expansion modules)
Inrush Current	12 A @ 28.8 VDC
I²t Value	0.8 A²·s
Backplane Bus Output	5 VDC, max. 1000 mA
Sensor Supply	24 VDC (L+ minus 4 VDC minimum)
Typical Power Loss	9 W
Work Memory	100 KB
RTC Accuracy	±60 s/month @ 25°C
Digital Input Voltage	24 VDC
Shock Resistance	15 g, 11 ms half-sine pulse (IEC 60068-2-27)
Digital Outputs	6 Relay Outputs
Output Current Rating	2 A per output (resistive load)
Lamp Load Rating	30 W DC / 200 W AC
Output Switching Time	≤10 ms
Relay Mechanical Life	10 million operations
Analog Inputs	2 integrated
Analog Input Range	0–10 V
Analog Input Resistance	≥100 kΩ
Analog Resolution	10-bit
PROFINET Speed	100 Mbit/s
Maximum Counter Frequency	100 kHz
Digital Input Isolation	500 VAC for 1 minute
Protection Rating	IP20
Operating Temperature	-20 to +60°C (horizontal), -20 to +50°C (vertical)
Storage Temperature	-40 to +70°C
Operating Air Pressure	795–1080 hPa
Storage/Transport Air Pressure	660–1080 hPa

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Siemens 6ES7212-1HE40-0XB0 SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU is a compact and high-performance programmable logic controller designed for small and medium-sized industrial automation applications. It features integrated digital inputs, relay outputs, analog inputs, high-speed counting, and PROFINET communication in a single compact unit. With fast processing performance, flexible expansion capability, and reliable 24 VDC operation, it provides an efficient solution for machine control, process automation, and industrial networking.

Functions

Executes PLC programs for industrial machine and process automation.
Controls field devices using integrated digital inputs and relay digital outputs.
Acquires analog voltage signals through two integrated 0–10 V analog input channels.
Supports high-speed counting applications with frequencies up to 100 kHz.
Communicates with HMIs, drives, remote I/O, and other industrial devices through the integrated PROFINET interface.
Provides relay outputs for controlling motors, contactors, valves, solenoids, and lighting circuits.
Supplies 24 VDC power for sensors and field devices connected to the control system.
Stores automation programs and process data using integrated work memory for reliable operation.
Supports expansion with Siemens S7-1200 signal, communication, and technology modules.
Ideal for packaging machinery, conveyor systems, material handling equipment, water treatment, HVAC, and factory automation applications.

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

FAQ

Q1: What is the 6ES7212-1HE40-0XB0 SIMATIC S7-1200 CPU 1212C DC/DC/Relay Compact PLC CPU used for?
A: The 6ES7212-1HE40-0XB0 is used to control industrial machines, production equipment, and automated processes in a wide range of industrial applications.

Q2: What power supply does the 6ES7212-1HE40-0XB0 require?
A: The 6ES7212-1HE40-0XB0 operates with a 24 VDC power supply and supports an input voltage range of 20.4–28.8 VDC.

Q3: How many relay outputs does the 6ES7212-1HE40-0XB0 provide?
A: The 6ES7212-1HE40-0XB0 provides six integrated relay digital outputs with a rated output current of 2 A per channel.

Q4: Does the 6ES7212-1HE40-0XB0 include analog inputs?
A: Yes. The 6ES7212-1HE40-0XB0 includes two integrated analog inputs supporting 0–10 V voltage signals with 10-bit resolution.

Q5: Does the 6ES7212-1HE40-0XB0 support PROFINET communication?
A: Yes. The 6ES7212-1HE40-0XB0 includes an integrated PROFINET interface with a communication speed of 100 Mbit/s.

Q6: What is the work memory capacity of the 6ES7212-1HE40-0XB0?
A: The 6ES7212-1HE40-0XB0 provides 100 KB of integrated work memory for user programs and data processing.
