Siemens 6ES7214-1BG40-0XB0 CPU Module

Product Name: CPU Module

Brand Name: Siemens

Model Number: 6ES7214-1BG40-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7214-1BG40-0XB0 is a compact and versatile PLC CPU module designed for medium-scale industrial automation applications. As part of the Siemens SIMATIC S7-1200 series, it integrates 14 digital inputs, 10 relay digital outputs, and 2 analog inputs within a single controller, providing efficient machine and process control in a compact footprint.

The CPU operates on a wide AC power supply range from 85 V to 264 V AC and supports flexible system expansion through Siemens SM and CM modules. With 150 KB of program and data memory and compatibility with STEP 7 V18 or higher, the module offers reliable performance, flexible programming, and seamless integration into modern automation systems.

Functions

Executes automation logic and process control tasks for industrial applications.
Provides 14 digital inputs for monitoring switches, sensors, and control signals.
Provides 10 relay outputs for controlling motors, relays, alarms, and industrial actuators.
Includes 2 analog inputs (0–10 V DC) for analog signal acquisition and monitoring.
Supports machine automation, sequencing, timing, and process management.
Enables system expansion through SIMATIC S7-1200 signal modules (SM) and communication modules (CM).
Processes digital and analog signals simultaneously for integrated automation control.
Supports programming, diagnostics, and monitoring through STEP 7 V18 or higher.

Features

Compact CPU 1214C AC/DC/Relay design for space-saving installations.
Integrated onboard I/O:
- 14 digital inputs (24 V DC)
- 10 relay outputs (2 A)
- 2 analog inputs (0–10 V DC)
Wide AC operating voltage range:
- 85 V to 264 V AC
- Frequency range: 47 Hz to 63 Hz
Low energy consumption:
- Rated current: 100 mA at 120 V AC
- Rated current: 50 mA at 240 V AC
Maximum current consumption:
- 300 mA at 120 V AC
- 150 mA at 240 V AC
Maximum inrush current of 20 A at 264 V for stable startup performance.
150 KB integrated program and data memory for flexible application development.
Backplane bus support up to 1600 mA at 5 V DC for expansion modules.
Compatible with STEP 7 V18 or higher.
Firmware version V4.6 for enhanced system functionality.
Compact dimensions of approximately 11 × 7.4 × 9.9 cm.
Lightweight industrial design with a weight of 0.44 kg.
Manufactured in Germany for high industrial reliability and durability.

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7214-1BG40-0XB0 CPU Module
Manufacturer	Siemens
Product Type	CPU Module
Part Number	6ES7214-1BG40-0XB0
Estimated shipping dimensions	11x7.4x9.9cm
Weight	0.44kg
Place of shipment	Xiamen, China
Country of origin	Germany
Product type designation	CPU 1214C AC/DC/relay
Firmware version	V4.6
Programming package	STEP 7 V18 or higher
permissible range, lower limit (AC)	85 V
permissible range, upper limit (AC)	264 V
permissible range, lower limit	47 Hz
permissible range, upper limit	63 Hz
Current consumption (rated value)	100 mA at 120 V AC; 50 mA at 240 V AC
Current consumption, max.	300 mA at 120 V AC; 150 mA at 240 V AC
Inrush current, max.	20 A; at 264 V
for backplane bus (5 V DC), max.	1600 mA; Max. 5 V DC for SM and CM
onboard I/O	14 DI24 V DC
10 DO relay 2 A	2 AI 0-10 V DC
power supply	AC 85-264 V AC at 47-63 Hz

Application Scenarios

The Siemens 6ES7214-1BG40-0XB0 is widely used in industrial automation and machine control systems, including:

Manufacturing and assembly automation
Conveyor and material handling systems
Packaging machinery
Industrial process control
Water and wastewater treatment systems
HVAC and building automation
Energy management systems
Small-to-medium machine automation
Monitoring and control panels
Industrial equipment retrofitting and modernization

Its integrated digital and analog I/O capabilities make it especially suitable for compact automation systems requiring flexible signal handling and reliable relay output control.

Operating Environment

The Siemens 6ES7214-1BG40-0XB0 is designed for stable operation in industrial environments with varying power conditions. It supports a wide AC supply voltage range from 85 V to 264 V AC and operates reliably within a frequency range of 47 Hz to 63 Hz. The module features controlled inrush current characteristics for smooth startup and efficient power management during continuous operation. Its robust industrial construction, integrated relay outputs, and support for expansion modules ensure dependable long-term performance in demanding automation applications and industrial control cabinets.
