Siemens 6ES7215-1HG40-0XB0 CPU1215C Compact Unit

Siemens 6ES7215-1HG40-0XB0 CPU1215C Compact Unit

Product Name: CPU1215C Compact Unit

Brand Name: Siemens

Model Number: 6ES7215-1HG40-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7215 1hg40 0xb0 cpu1215c compact unit-1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7215-1HG40-0XB0 is a compact and powerful programmable logic controller (PLC) designed for industrial automation and process control applications. As part of the Siemens SIMATIC S7-1200 series, this CPU 1215C compact unit features a DC/DC/Relay configuration with integrated digital and analog I/O, providing flexible and reliable control for machinery, manufacturing systems, and process automation environments.

The controller supports dual PROFINET communication ports for advanced network integration and redundancy, ensuring stable communication and automatic failover during network interruptions. With onboard relay outputs, analog I/O capability, and support for STEP 7 programming, the module offers a comprehensive and efficient automation solution for OEMs and system integrators.

Functions

Executes industrial automation logic and machine control operations.
Provides integrated digital inputs for signal acquisition from sensors and switches.
Provides relay outputs for direct switching of industrial loads and actuators.
Supports analog input and output processing for process control applications.
Supplies stable DC power processing for onboard and expansion modules.
Enables seamless communication through integrated dual PROFINET ports.
Supports automatic network failover and redundant communication functions.
Processes complex automation tasks including sequencing, PID control, motion control, and data logging.
Expands automation systems through compatible Siemens S7-1200 expansion modules.

Features

Compact CPU 1215C DC/DC/Relay controller for space-saving automation systems.
Integrated onboard I/O configuration:
- 14 digital inputs (24 V DC)
- 10 relay outputs (2 A)
- 2 analog inputs (0–10 V DC)
- 2 analog outputs (0–20 mA DC)
Dual integrated PROFINET ports for industrial Ethernet communication and network redundancy.
Wide DC operating voltage range:
- 20.4 V DC to 28.8 V DC
Reverse polarity protection for enhanced electrical safety.
Current consumption:
- 500 mA typical for CPU only
- Up to 1,500 mA with expansion modules
Maximum inrush current:
- 12 A at 28.8 V DC
Typical power loss of 12 W.
125 KB integrated program and data memory for advanced automation applications.
Compatible with STEP 7 V13 SP1 or higher.
Input resistance for analog inputs:
- ≥100 kΩ (0–10 V)
Compact dimensions of approximately 13 × 10 × 7.5 cm.
Lightweight industrial design with a weight of 0.44 kg.
Manufactured in Germany for reliable industrial performance.

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7215-1HG40-0XB0 CPU1215C Compact Unit
Manufacturer	Siemens
Product Type	CPU1215C Compact Unit
Part Number	6ES7215-1HG40-0XB0
Estimated shipping dimensions	13x10x7.5cm
Weight	0.44kg
Place of shipment	Xiamen, China
Country of origin	Germany
Product type designation	CPU 1215C DC/DC/Relay
Firmware version	V4.1
Programming package	STEP 7 V13 SP1 or higher
with display	No
permissible range, lower limit (DC)	20.4 V
permissible range, upper limit (DC)	28.8 V
Reverse polarity protection	Yes
Current consumption (rated value)	500 mA; CPU only
Current consumption, max.	1 500 mA; CPU with all expansion modules
Inrush current, max	12 A; at 28.8 V DC
Power loss, typ	12 W
Input resistance (0 to 10 V)	≥100k ohms

Application Scenarios

The Siemens 6ES7215-1HG40-0XB0 is suitable for a wide range of industrial automation and process control applications, including:

Conveyor and material handling systems
Packaging and assembly machinery
Manufacturing automation systems
HVAC and building automation
Temperature, pressure, and flow control applications
Water treatment and utility systems
OEM machine control solutions
Process automation and monitoring systems
Motion control and sequencing applications
Industrial network systems requiring redundant PROFINET communication

Its integrated analog and relay I/O capabilities make it especially suitable for compact automation systems requiring both discrete and analog process control.

Operating Environment

The Siemens 6ES7215-1HG40-0XB0 is designed for reliable operation in demanding industrial environments. It operates with a stable DC supply voltage range from 20.4 V to 28.8 V DC and includes reverse polarity protection to enhance operational safety under fluctuating power conditions. The controller supports continuous operation with efficient power management and controlled inrush current characteristics. Its robust construction, integrated communication ports, and compatibility with Siemens S7-1200 expansion modules ensure dependable long-term performance in industrial control cabinets, manufacturing systems, and networked automation environments.
