Siemens 6ES7222-1BH32-0XB0 SM 1222 Digital Output Module

Siemens 6ES7222-1BH32-0XB0 SM 1222 Digital Output Module

Product Name: SM 1222 Digital Output Module

Brand Name: Siemens

Model Number: 6ES7222-1BH32-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7222 1bh32 0xb0 sm 1222 digital output module-1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens SIMATIC S7-1200 SM 1222 Digital Output Module with part number 6ES7222-1BH32-0XB0 is a digital output expansion module designed for the Siemens SIMATIC S7-1200 programmable logic controller (PLC) series. It is mainly used to expand the PLC’s digital output capacity, enabling the control of multiple field devices in industrial automation systems with stable and reliable performance.

This module is equipped with 16 transistor digital outputs (16 DO) and operates at a rated voltage of 24 V DC. Each output channel supports up to 0.5 A output current, allowing the module to control relays, solenoid valves, contactors, indicators, and other industrial DC loads. Its transistor output design provides fast switching speed and high response efficiency, making it suitable for high-speed automation applications.

The Siemens SM 1222 module features a compact structure, low power loss, and easy integration into control cabinets and automation equipment. Manufactured in Germany, it meets Siemens industrial quality standards and is widely applied in factory automation, process control, packaging machinery, conveyor systems, and intelligent manufacturing environments requiring dependable digital output control.

Functions

Expands the digital output capacity of Siemens S7-1200 PLC systems.
Provides 16 independent digital transistor outputs for controlling external devices.
Enables high-speed switching operations for automation processes.
Supports ON/OFF control of industrial actuators and field devices.
Interfaces with relays, solenoid valves, contactors, indicators, and other DC loads.
Delivers stable 24 V DC signal output for industrial control applications.

Features

16-channel digital transistor output module for Siemens SIMATIC S7-1200 PLC systems
High-speed transistor outputs suitable for fast switching applications
Supports 24 V DC rated output voltage
Output current capacity up to 0.5 A per channel
Reliable and stable signal transmission for industrial automation control
Low power consumption with typical power loss of 2.5 W
Compact and space-saving design for easy panel installation
Lightweight structure with approximately 0.18 kg weight
Excellent compatibility with Siemens S7-1200 automation platforms
Durable industrial-grade construction for long-term operation
Provides efficient control of relays, solenoid valves, contactors, and indicator devices
Easy integration and maintenance within industrial control systems
Designed and manufactured according to Siemens industrial quality standards in Germany
Suitable for continuous operation in demanding automation environments

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7222-1BH32-0XB0 SM 1222 Digital Output Module
Manufacturer	Siemens
Product Type	SM 1222 Digital Output Module
Part Number	6ES7222-1BH32-0XB0
Estimated shipping dimensions	4.5x7.5x10cm
Weight	0.18 kg
Place of shipment	Xiamen, China
Country of origin	Germany
Model	SM 1222
Outputs	16 DO (16 Digital Outputs)
Output Type	Transistor
Rated Voltage	24 V DC
Output Current	0.5 A per output
Power Loss	Typical 2.5 W
Signal “0” Voltage	Max. 0.1 V (with 10 kΩ load)
Signal “1” Voltage	Min. 20 V DC

Application Scenarios

The Siemens 6ES7222-1BH32-0XB0 SM 1222 digital output module is widely used in industrial automation and control systems, including:

Factory automation systems
Conveyor and material handling systems
Packaging machinery
Assembly production lines
Process control systems
Motor starter and relay control
Industrial robotics
Building automation systems
Water treatment equipment
Energy and power management systems

It is particularly suitable for applications requiring fast and accurate digital switching control.

Operating Environment

Installation Environment: Industrial control cabinets or automation panels.
Operating Voltage: 24 V DC system environment.
Recommended Usage: Clean, dry, and well-ventilated industrial environments.
Protection Requirements: Avoid exposure to excessive dust, corrosive gases, moisture, vibration, and direct sunlight.
Temperature Conditions: Suitable for standard industrial operating temperatures when installed according to Siemens guidelines.
Transportation & Storage: Handle carefully to avoid electrostatic discharge (ESD) and mechanical damage during shipping and storage.
