Siemens 6ES7222-1HF32-0XB0 SM 1222 Digital Output Module

Siemens 6ES7222-1HF32-0XB0 SM 1222 Digital Output Module

Product Name: SM 1222 Digital Output Module

Brand Name: Siemens

Model Number: 6ES7222-1HF32-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7222 1hf32 0xb0 sm 1222 digital output module-1

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7222-1HF32-0XB0 is an SM 1222 digital output module developed for the SIMATIC S7-1200 automation platform. It provides 8 relay-based digital output channels for controlling industrial field devices and electrical loads within PLC systems.

This module is designed to expand the output capabilities of S7-1200 controllers while offering reliable switching performance for both AC and DC applications. Its relay output design enables flexible control of actuators, lamps, contactors, and other industrial equipment requiring electrical isolation and stable switching operation.

The compact modular structure of the 6ES7222-1HF32-0XB0 allows efficient installation in industrial control cabinets. With dependable relay technology and compatibility with a wide range of load voltages, the module is suitable for machine automation, production systems, and industrial process control applications.

Functions

Provides 8 relay-based digital output channels
Controls external AC and DC industrial loads
Expands the output capacity of S7-1200 PLC systems
Interfaces PLC logic signals with field devices and actuators
Supports reliable switching for industrial automation equipment
Enables control of lamps, relays, solenoid valves, and contactors

Features

8 Relay Digital Outputs
Provides 8 independent relay output channels for flexible industrial load control.
AC and DC Load Compatibility
Supports switching of:
- 5V DC to 30V DC
- 5V AC to 250V AC
High Output Switching Capacity
Each output channel supports resistive loads up to 2 A for reliable device control.
Relay-Based Electrical Isolation
Relay output design improves switching reliability and supports various industrial applications.
Lamp Load Handling Capability
Supports lamp loads up to:
- 30 W with DC
- 200 W with AC
Stable 24V DC Power Operation
Operates within a 20.4–28.8V DC supply voltage range.
Low Power Consumption Design
Typical power loss of approximately 4.5 W for efficient continuous operation.
Compact Modular Construction
Space-saving module suitable for DIN rail installation in industrial control cabinets.
Seamless S7-1200 Integration
Designed for direct compatibility with the SIMATIC S7-1200 platform.
Industrial-Grade Reliability
Engineered for stable performance in environments with vibration, electrical interference, and long-term operation requirements.

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7222-1HF32-0XB0 SM 1222 Digital Output Module
Manufacturer	Siemens
Product Type	SM 1222 Digital Output Module
Part Number	6ES7222-1HF32-0XB0
Estimated shipping dimensions	4.4x7.4x9.9cm
Weight	0.16kg
Place of shipment	Xiamen, China
Country of origin	Germany
Product type designation	SM 1222, DQ 8x relay/2 A
Supply voltagepermissible range, lower limit (DC)	20.4 V
permissible range, upper limit (DC)	28.8 V
from backplane bus 5 V DC, max.	120 mA
from load voltage L+, max.	11 mA/relay coil
Power loss, typ.	4.5 W
Number of digital outputs	8
in groups of	2
Short-circuit protection	No; to be provided externally
with resistive load, max.	2 A
on lamp load, max.	30 W with DC, 200 W with AC
Rated value (DC)	5 V DC to 30 V DC
Rated value (AC)	5 V AC to 250 V AC
